32/1000 Box Profile Roll Forming Machine – Complete Guide & Specifications

High-performance 32/1000 box profile roll forming machine for roofing and cladding. Full specifications, profiles, applications, pricing

November 16, 2025

The 32/1000 box profile—also known as the trapezoidal 32/1000 roofing sheet—is one of the most widely used metal roofing and cladding profiles in Europe, the UK, Ireland, and Africa. Its popularity is driven by its versatility, structural strength, and compatibility with both residential and commercial buildings. For manufacturers, steel service centers, and metal roofing suppliers, a dedicated 32/1000 box profile roll forming machine is a high-demand, high-volume production asset capable of serving almost every segment of the construction industry.

This complete guide explains everything you need to know before purchasing a 32/1000 box profile roll forming machine, including its specifications, output capabilities, global market usage, power supply requirements, accessories, installation process, and maintenance standards. As with all Machine Matcher equipment, these machines are built new, made to your profile drawing, and delivered worldwide with full support from our technical teams in the United Kingdom and United States.

1. What Is a 32/1000 Box Profile Roll Forming Machine?

A 32/1000 box profile roll forming machine is an automated metal-forming line designed to produce roofing and cladding sheets with a 1000mm cover width and a trapezoidal rib height of 32mm. The machine pulls in steel coil (typically 0.30–0.70 mm thick), gradually shapes the ribs through a sequence of rollers, and cuts panels to the programmed lengths.

The box profile is characterized by:

• 32mm rib height

• 1000mm cover width

• Three major trapezoidal ribs

• Low/middle rib reinforcement for added stiffness

• A clean, modern appearance

• High load-bearing strength compared to corrugated profiles

This design makes the 32/1000 profile a top seller across Europe, the UK, and Africa for both roofing and wall cladding.

2. 32/1000 Box Profile Machine Specifications

Specification	Details
Machine_ID	MM-BP32-1000
Machine_Family	Roofing Panel Roll Forming Line
Machine_Type	32/1000 Box Profile Roll Forming Machine
Alternate_Names	Box profile machine, trapezoidal sheet machine, T18 machine
Region_Popularity	UK, Ireland, Poland, Romania, Spain, France, Greece, South Africa
Profiles_Produced	32/1000 trapezoidal, T18/T20 variations
Gauge_Range_mm	0.30–0.70 mm
Materials	GI, GL, PPGI, PPGL, Aluminum
Tensile Range	235–550 MPa
Production Speed	12–45 m/min
Roller Stations	14–20
Roller Material	GCr15 hardened, chrome plated
Shaft Material	40Cr, 60–75mm shafts
Cutting Type	Hydraulic cut-off (standard), flying shear optional
Punching Type	Crest/valley punching (optional)
Power Supply	380–415V 50Hz / 220–480V 60Hz
Motor Power	5.5–11 kW
Hydraulic Power	4–7.5 kW
Control System	Siemens / Mitsubishi / Delta PLC & HMI
Automation	Fully automatic encoder length control
Line Configuration	Decoiler → Forming → Cut → Runout
Coil Width Range	1200–1250 mm
Coil Thickness Range	0.30–0.70 mm
Accessories Included	Decoiler, run-out table, spare blades
Optional Extras	Auto decoiler, stacker, coil car, embossing, noise cover
Applications	Roofing, cladding, fencing
Industries	Construction, warehousing, agriculture
Common Countries	UK, Ireland, Poland, Romania, Spain, Africa
Price Range (USD)	$26,000–$120,000
SEO Keywords	32/1000 box profile machine, trapezoidal sheet line
Tags	roofing sheet, trapezoidal, box profile
Notes	The most common roofing sheet in Europe

3. 32/1000 Box Profile Sketch

 /‾‾\ /‾‾\ /‾‾\
_____/ \______/ \______/ \_____

4. Profile Description (32/1000 Box Profile Explained)

The 32/1000 box profile is a modern trapezoidal metal sheet widely used across Europe and the UK in roofing, cladding, and fencing. The numbers represent:

• 32mm rib height for improved strength

• 1000mm cover width for efficient installation

This profile provides an ideal balance between aesthetics, durability, and cost-effectiveness. It is manufactured from pre-painted or galvanized steel coil, making it suitable for harsh years-round climates.

Key Benefits

• Clean, modern trapezoidal design

• Excellent structural rigidity

• Fast installation

• Suitable for both roofing and wall cladding

• Compatible with anti-condensation backing

• High resistance to wind uplift

• Low noise vibration due to rib structure

Common Uses

• Residential roofs

• Industrial warehouses

• Steel-frame buildings

• Garages & workshops

• Agricultural barns

• Container conversion & modular buildings

• Retail units & commercial façades

Available Variants

• 32/1000 T18

• 32/1000 T20

• 32/1000 XL (reinforced rib)

• 32/1000 wall cladding profile

5. How the Machine Works

The 32/1000 box profile roll forming line is a fully automated system. Here is the complete workflow:

1. Coil Decoiling

Coil (1.2–1.25m wide) is loaded onto a manual or hydraulic decoiler. Tension control ensures smooth feeding.

2. Feeding & Leveling

A pinch feeder or servo feeder grips the material. Optional leveling ensures consistent panel quality.

3. Roll Forming

14–20 forming stations gradually shape the trapezoidal ribs. Tooling is engineered for:

• Precise rib geometry

• No surface scratching

• High-speed accuracy

• Long-term durability

4. PLC Length Control

A precision encoder detects strip movement and triggers the cutting cycle.

5. Cutting

The panel is cut to length using:

• Hydraulic guillotine (standard)

• Flying shear (high-speed production)

6. Run-Out Table or Automatic Stacker

Panels are discharged automatically and stacked if required.

6. Applications

The 32/1000 box profile is used in:

Residential Construction

• New build roofing

• Extensions & conservatories

• Carports and garages

Commercial & Industrial Buildings

• Warehouses

• Factories

• Shopping centers

• Auto service units

Agricultural Buildings

• Barns

• Milking parlours

• Grain storage

• Animal shelters

Other Uses

• Boundary fencing

• Container conversion

• Modular housing

• Façade panels

7. Industries Using 32/1000 Roofing Sheets

• Construction

• Agriculture

• Manufacturing

• Cold storage

• Retail/commercial

• Real estate development

• Roofing contractors

• Steel suppliers

8. Global Market Demand

United Kingdom

The most popular roofing sheet for homes, industrial sheds, farms, and garages.

Ireland

Used heavily in agricultural buildings and coastal installations.

Poland, Romania, Greece, France, Germany

Dominant profile for steel roofing suppliers and metal building manufacturers.

Africa (South Africa, Kenya, Ghana, Nigeria)

Growing demand due to affordability and excellent heat/wind resistance.

Middle East

Used mainly for cladding and fencing rather than roofing.

9. Price Guide

Entry-Level Machine

$26,000 – $45,000
Manual decoiler, 12–15 m/min speed, hydraulic cut-off.

Mid-Range Machine

$45,000 – $85,000
Powered decoiler, better tooling, 20–30 m/min.

High-End Industrial Line

$85,000 – $120,000
Flying shear, automatic stacker, noise cover, 40–45 m/min.

Additional Costs

• Crating and export packaging

• Sea freight

• Local import taxes

• Installation & commissioning

• Spare blades, rollers, oils

10. Optional Extras

• Hydraulic decoiler (3–10T)

• Automatic coil car

• Automatic panel stacker

• Noise reduction cover

• Servo feeder

• Embossing roller unit

• Vent punching system

• Remote PLC access (Ewon, Siemens)

• Safety guarding enclosure

11. Setup & Installation Requirements

Factory Space

20–28 meters length recommended.

Power Requirements

Europe: 380–415V, 50Hz
USA: 230–480V, 60Hz

Installation Timeline

1. Unloading & positioning

2. Electrical & hydraulic connection

3. Roller alignment

4. Testing with coil

5. Calibration & programming

6. Full-speed production

12. Maintenance Requirements

Daily

• Check rollers for dirt

• Inspect sensors & encoder

• Check hydraulic fluid

Weekly

• Lubricate bearings & chains

• Clean tooling and guides

• Check blade sharpness

Monthly

• Tighten bolts

• Test PLC system

• Inspect hydraulic unit

13. Frequently Asked Questions (Q&A)

Q1: What is the cover width of the 32/1000 profile?

1000mm.

Q2: What coil width is needed?

1200–1250mm depending on rib design.

Q3: What thicknesses can it run?

0.30–0.70 mm.

Q4: Can it run pre-painted material?

Yes — rollers are polished and chrome coated.

Q5: Can it run aluminum?

Yes, up to 0.7 mm.

Q6: What is the standard speed?

12–45 m/min.

Q7: Does it need a foundation?

A flat concrete floor is sufficient.

Q8: Can it produce cladding and fencing panels?

Yes.

Q9: Is a flying shear required?

Only for high-volume production.

Q10: How long does installation take?

2–4 days.

Q11: Do you offer profile customization?

Yes — any drawing can be produced.

Q12: What’s the lifespan of the rollers?

8–10 years depending on usage.

Q13: Do you provide worldwide delivery?

Yes — all countries covered.

Q14: Do you include training?

Yes — both on-site and remote.

Q15: What after-sales support is included?

24/7 remote technical support.

14. Machine Matcher – Global Supplier of New Roll Forming Machines

Machine Matcher supplies brand-new roll forming machines, built to your exact profile drawing and delivered to any location worldwide. Our technical teams in the UK and USA support you with:

• Custom machine design

• Profile engineering

• Installation & commissioning

• Electrical/PLC diagnostics

• Spare parts & upgrades

• 24/7 global remote support
