Iron Sheet Making/Press/Rolling Machine |
|
Suitable material |
PPGI/Aluminium sheet/galvanized sheet/various sheet plates |
Thickness of coil sheet |
0.15mm |
Coil width |
914mm |
Material of main frame |
350H steel |
Diameter of Soild shaft |
70mm, high grade 45# steel |
Roller |
Quenched and tempered treatment, hard chrome coated 0.05-0.07mm |
Thickness of middle plate |
16mm |
Forming station |
16stations |
Drive type |
By chain(1.0 inch) link bearing model 6210 |
Power of main motor |
5.5kw with Cycloidal reducer |
Power of pump station |
3kw |
Forming speed |
About 30-35m/min |
Hydraulic cutting |
Controlled by PLC |
PLC |
DELTA(TAIWAN)/Mitsubishi |
Material of razor blades |
Cr 12, quenching 58-62ºC |
Frequency converter |
It has the advantage of slowing down before cutting, to ensure the length accuracy(±1mm, far better than industrial standard ±3mm). |
