| Processing Material | PPGI,GI,Aluminium |
| Input Width | 1250mm (as customer needing) |
| Formed Width | 915mm (as customer needing) |
| Processing Thickness | 0.3--0.7mm |
| Material of Rollers | 45# steel,with heat treatment |
| Diameter of Shaft | Ф70mm |
| Production Speed | 12---15m/min |
| Roller Driven | Decelerating Motor+Chain Transmission |
| Cutting Model | Hydraulic Profile Cutting |
| Length Measurement | Encoder |
| Control Style | PLC |
| Operation Model | Button + Touch Screen |
| Total Power | 6kw |
| Voltage | 380V 50HZ or at buyer's request |
