| 1 | Suitable to process | Color steel plate, galvanized sheet, aluminum coils and etc. |
| 2 | Width of the feeding material | 1250mm |
| 3 | Roller station | 11-22 rows or custom as customer's requirements |
| 4 | Thickness of feeding material | 0.3-0.8mm |
| 5 | Productivity | 8-12m/min |
| 6 | Rollers' material | 45# steel |
| 7 | Diameter of shaft | 80mm |
| 8 | Voltage | 380V 50Hz 3phases |
| 9 | Wall thickness of main forming machine | 14mm steel plate |
| 10 | Main forming machine body | 300 mm H steel |
| 11 | Motor power | 4+3kw |
| 12 | Size | 7500*1500*1400mm |
| 13 | Weight | About 4.6 T |
