Metal Decking Roll Forming Machine – United Arab Emirates

Overview:
Our Metal Decking Roll Forming Machine is the ideal solution for companies across the UAE involved in large-scale construction and infrastructure projects. This machine is engineered to produce high-quality metal decking sheets that serve as essential components in modern building structures, offering strength, stability, and efficiency for flooring, roofing, and composite slab applications.

Designed for precision, speed, and reliability, every machine is custom-built to your specific profile requirements. Whether your project is located in Abu Dhabi, Dubai, Sharjah, or anywhere else in the UAE, we ensure fast delivery and full local support.

Machine Technical Specifications:

• Machine Type: Metal Decking Roll Forming Machine

• Production Speed: Up to 15–20 meters per minute (variable based on profile and material)

• Material Thickness Range: 0.8 mm – 1.5 mm

• Material Width Range: 1000 mm – 1500 mm

• Material Types: Galvanized Steel (GI), Galvalume (GL), Aluminum

• Material Yield Strength: Up to 550 MPa

• Roller Material: High-Grade 45# Steel

• Roller Surface Treatment: Hard Chrome Plating for wear resistance

• Number of Forming Stations: 22–28 Stations (depending on profile)

• Roller Shaft Diameter: 75 mm

• Shaft Material: Solid 40Cr Steel (quenched and tempered)

• Main Drive Type: Chain or Gear Drive (depending on customer preference)

• Power (for UAE location): 380V, 50Hz, 3 Phase (Customized if needed)

• Motor Power: 15–22 kW

• Cutting Method: Hydraulic Cutting Post-forming

• Blade Material: Cr12Mov Steel, heat-treated

• Control Type: PLC Automated Control System (brands like Siemens, Delta, Mitsubishi available)

• Operating Mode: Fully Automatic, Semi-Automatic Option Available

• De-coiling System: Manual or Hydraulic De-coiler (up to 5–10 tons capacity available)

• Punching/Notching System: Optional integrated hydraulic punching unit before forming

• Machine Frame: Heavy-duty Welded Steel Frame

• Thickness of Frame Steel: 20 mm

• Profile Shape: Customized Metal Decking Profile (trapezoidal, ribbed, or special designs)

• Profile Width and Depth: Standard and Customizable (Example: 600–1000 mm width, 50–80 mm depth)

• Length Tolerance: ±2 mm per 6 meters

• Safety Features:

  • Protective Covers/Guards around moving parts

  • Emergency Stop Button

  • Overload Protection System

Industry Applications:

This Metal Decking Roll Forming Machine is critical for the construction, commercial building, industrial infrastructure, and residential high-rise sectors.
It is ideal for producing:

• Composite floor decking

• Roofing structures

• Bridge flooring

• Warehouse mezzanines

• Stadium and airport construction decking

The UAE’s booming construction sector—especially mega-projects in Dubai, Abu Dhabi, and Sharjah—makes metal decking sheets an in-demand product for both domestic and export markets.

Delivery and Warranty:

All our Metal Decking Roll Forming Machines are new, custom-built, and can be delivered anywhere in the UAE, including Dubai, Abu Dhabi, Sharjah, and all major industrial zones.
Machines are covered by a one-year warranty from dispatch, including full maintenance, repair, and after-sales support.

Pricing is determined based on optional extras and customization details.
For the best quotation, please email your profile drawings, material details, or any specific requirements to [email protected].

Frequently Asked Questions (FAQ)

Q1: Can the machine produce different decking profiles?
A: Yes. Each machine can be customized to produce your required profile. We can design the rollers according to your drawings or sample sheets.

Q2: What kind of material can I use?
A: You can use galvanized steel, Galvalume, or aluminum sheets with thicknesses ranging from 0.8 mm to 1.5 mm, depending on your project needs.

Q3: How long does manufacturing and delivery take for the UAE?
A: Standard production time is around 60–75 days depending on customization. Delivery to UAE ports like Jebel Ali can take an additional 20–30 days.

Q4: Is on-site installation and commissioning available in the UAE?
A: Yes, we offer remote installation support. On-site setup and training services in the UAE are available at an extra cost if required.

Q5: Can I add a punching unit to the machine?
A: Yes, an integrated hydraulic punching and notching unit can be added as an optional feature based on your design needs.

Q6: What safety measures are included?
A: Our machines include protective guards over moving parts, emergency stop buttons, and an overload protection system to ensure safe operation.

Q7: What if I need spare parts after purchase?
A: We supply all spare parts and offer maintenance support. Fast shipping of critical parts to the UAE is also available.

Why Choose Machine Matcher for Your Metal Decking Roll Forming Machine in the UAE?

• Custom design based on your profile needs

• Fast and reliable delivery across UAE cities

• Full maintenance and after-sales support

• One-year warranty and technical backup

• Professional consulting to match you with the right machine

For a fast and tailored quote, or to discuss your project, please email us today at [email protected].
