Roof Sheet Roll Forming Machine – United Arab Emirates
Precision-Crafted for the UAE's Roofing Industry – Custom-Built & Delivered Nationwide
The Roof Sheet Roll Forming Machine is engineered for producing high-quality metal roofing panels widely used in the residential, commercial, and industrial sectors across the UAE. Built for strength, reliability, and efficiency, this roll forming machine delivers consistent performance in high-output environments such as roofing panel production facilities and metal building manufacturers.
Optimized for the UAE market, this machine is suitable for the production of various popular roof sheet profiles like IBR, corrugated, and trapezoidal panels. All machines are custom-built and delivered directly to Abu Dhabi, Dubai, Sharjah, and other Emirates.
Custom Profile Capability: Machines are tailored to your exact profile drawing—ensuring zero waste and perfect fitment.
Built for UAE Conditions: Electrical systems and machine configurations are adapted to the regional power supply and heat environment.
High-Speed, High-Accuracy Output: Up to 40m/min with ±1mm length tolerance, allowing for fast project turnarounds.
Long-Term Investment Value: Built with hardened and coated rollers for longevity—reducing maintenance frequency and cost.
Flexible Material Compatibility: Supports a wide range of coated and bare steels and aluminum.
After-Sales Peace of Mind: One-year warranty plus lifetime technical support.
Metal Roofing Contractors & Fabricators
Pre-Engineered Metal Building (PEMB) Manufacturers
Steel Construction Companies
Modular and Prefab Building Suppliers
Residential & Commercial Roofing Installers
Steel and Metal Panel Wholesalers
Common Applications:
Roof panels for warehouses, factories, homes, and commercial buildings
Retrofit and repair panels for existing structures
Fast-turnaround custom panel production for UAE construction projects
| Specification | Detail |
|---|---|
| Machine Type: | Roof Sheet Roll Forming Machine |
| Production Speed: | 12–40 meters per minute |
| Material Thickness Range: | 0.3 mm – 0.8 mm |
| Material Width Range: | 914 mm – 1250 mm (depends on profile) |
| Material Types: | Galvanized Steel, Galvalume, Aluminum, Painted Steel |
| Material Yield Strength: | Up to 550 MPa (80 ksi) |
| Roller Material: | GCr15 high-grade steel |
| Roller Surface Treatment: | Hard chrome-plated |
| Number of Forming Stations: | 14–22 stations (customizable) |
| Roller Shaft Diameter: | 70 mm |
| Shaft Material: | Solid 45# steel, precision machined |
| Main Drive Type: | Chain or gearbox drive (based on load) |
| Power – UAE Configuration: | 380V / 3 Phase / 50 Hz |
| Motor Power: | 7.5 kW – 15 kW (depends on model) |
| Cutting Method: | Hydraulic post-cut |
| Blade Material: | Cr12Mov, heat-treated |
| Control Type: | PLC system with touchscreen HMI |
| Operating Mode: | Fully automatic, manual override included |
| De-coiling System: | Manual or hydraulic uncoiler (optional) |
| Punching/Notching System: | Optional hydraulic unit before forming |
| Machine Frame: | Welded steel structure |
| Frame Steel Thickness: | 20 mm |
| Profile Shape: | Corrugated, Trapezoidal, IBR (customizable) |
| Profile Width and Depth: | Varies (typically 1000 mm effective cover, 28–45 mm depth) |
| Length Tolerance: | ±1 mm |
| Safety Features: | Protective covers, Emergency stop, Overload protection |
Galvanized Steel (GI): 0.4–0.8 mm | 240–550 MPa
Galvalume: 0.4–0.7 mm | 340–550 MPa
Aluminum: 0.4–0.6 mm | 150–300 MPa
Pre-Painted Steel: 0.3–0.7 mm | 250–350 MPa
Prices Start From: USD $36,000
Pricing varies based on profile complexity, automation level, and optional extras.
What Affects Final Price:
Profile design and width
Required output speed
Motor and cutting system type
Punching/notching features
Uncoiler or stacker add-ons
Shipping and installation options
Location: Delivered across UAE, including Dubai, Abu Dhabi, Sharjah, and other Emirates.
All machines are new, custom-built, and backed by a one-year warranty.
Profile tooling for custom roof designs
Servo feeder for higher accuracy
Remote-access PLC control system
Coil car + Hydraulic decoiler
Automatic stacking system
Roofing sheet embossing unit
Extended safety enclosure package
To receive a tailored quotation, email your profile drawing, material gauge, and expected usage details to:
[email protected]
Q: What is the production time for custom-built machines?
A: Production typically takes 30–50 days depending on the level of customization.
Q: Can the machine run aluminum or color-coated sheets?
A: Yes. The rollers and drive system are suitable for aluminum and coated steel.
Q: Do you offer on-site installation in the UAE?
A: Yes, our team or partners provide full installation and training within the UAE.
Q: What kind of profiles can this machine produce?
A: IBR, trapezoidal, corrugated, and any custom roof panel profiles based on your drawing.
Q: Can we include a stacker or an embossing system?
A: Yes, optional extras such as stackers, embossers, and remote PLCs are available.
For more information, custom solutions, or immediate assistance, contact us today and let Machine Matcher connect you to the ideal Roof Sheet Roll Forming Machine for your business in the UAE.
