Supplied by Machine Matcher
Machine Matcher is proud to offer top-tier Wall Cladding Sheet Roll Forming Machines, tailored for the dynamic construction landscape of the United Arab Emirates, including Abu Dhabi, Dubai, and Sharjah. These machines are custom-built to meet specific profile and machine requirements, ensuring optimal performance and efficiency.Machine Matcher
Our Wall Cladding Sheet Roll Forming Machines cater to a diverse range of industries:
Construction: For residential, commercial, and industrial roofing and wall cladding solutions.
Oil & Gas: Providing durable cladding for refineries and offshore platforms.
Warehousing: Manufacturing weather-resistant roofing systems.
Manufacturing: Producing components for metal building systems and pre-engineered buildings.
Agriculture: Creating cladding for barns and storage facilities.
Machine Type: Wall Cladding Sheet Roll Forming Machine
Production Speed: Up to 15–20 meters per minute
Material Thickness Range: 0.3 mm – 0.8 mm
Material Width Range: 600 mm – 1250 mm
Material Types: Galvanized Steel, Aluminum, Pre-painted Steel, Galvalume
Material Yield Strength: Up to 550 MPa
Roller Material: High-Grade Steel (Cr12 or GCr15)
Roller Surface Treatment: Hard Chrome Coated for corrosion resistance
Number of Forming Stations: 16–24 stations (depending on profile)
Roller Shaft Diameter: 70 mm
Shaft Material: Solid 45# Steel, heat-treated
Main Drive Type: Chain Drive or Gearbox Drive
Power: 380V, 50Hz, 3 Phase (customizable)
Motor Power: 7.5 kW – 11 kW (depending on requirements)
Cutting Method: Hydraulic Cutting (post-cut)
Blade Material: Cr12Mov (hardened steel)
Control Type: PLC Automatic Control System (brands like Siemens, Delta, or Mitsubishi)
Operating Mode: Full Automatic with touch screen HMI
De-coiling System: Manual or Hydraulic Decoiler (3–5 Ton)
Punching/Notching System: Optional hydraulic punching/notching station availableMachine Frame: Heavy-duty welded H-Beam steel frame
Thickness of Frame Steel: 18–22 mm
Profile Shape: Customizable roof and wall cladding profiles
Profile Width and Depth: Based on customer-provided drawings
Length Tolerance: ± 2 mm
Safety Features:
Protective Covers/Guards: Included around moving partsop Button: Installed at multiple accessible points
Overload Protection System: Integrated into electrical system
Machine Matcher offers extensive customization to meet your specific needs:
Profile Customization: Machines are built to your profile drawings and project specifications.
Power Specifications: Adaptable to your local power infrastructure.
Optional Extras: Including hydraulic decoilers, auto stackers, and punching stations.
Tailored Solutions: Each machine is custom-built to meet your specific profile and machine requirements.
Durability: Constructed with high-grade materials to withstand the UAE's harsh climate conditions.
Efficiency: High production speeds and precision reduce waste and increase output.
Safety: Integrated safety features ensure secure operations.
Support: Comprehensive after-sales support, including remote video guidance and on-site installation upon request.
Delivery Locations: Abu Dhabi, Dubai, Sharjah, Ajman, Fujairah, Ras Al Khaimah, Umm Al Quwain – and anywhere across the UAE.Machine Matcher
Warranty: 1-Year Warranty from dispatch date.Machine Matcher
After-Sales Support: Long-term maintenance, repair, and spare parts service available.Machine Matcher
Q: Can this machine produce custom roof cladding profiles for UAE building codes?
A: Yes, absolutely. We custom-build each machine according to the specific roof and wall cladding profile you need, based on UAE construction standards or your project-specific requirements.
Q: How fast can the machine operate?
A: The machine can produce panels at speeds of up to 15–20 meters per minute, depending on the material thickness and profile complexity.
Q: What kind of materials can be processed on this machine?
A: This machine can process galvanized steel, galvalume, aluminum, and pre-painted steel — all commonly used materials for roofing and cladding panels in the UAE.
Q: How accurate is the panel length control?
A: Thanks to the PLC control system, the machine maintains a ±2 mm length tolerance, ensuring precise panel lengths every cycle.
Q: Can I get a hydraulic decoiler with this machine?
A: Yes. We offer manual or hydraulic decoilers ranging from 3 to 5 tons capacity, depending on your production needs.
Q: Is installation and training available in the UAE?
A: Yes, installation guidance, remote support, and operator training are available to customers throughout the UAE.
Q: How is the machine protected during operation?
A: The machine includes full protective guards, emergency stop buttons, and an overload protection system to ensure safe operation at all times.
Starting Price: Prices start from $45,000 USD.
Factors Affecting Final Price:
Optional extras and customization requirements.
Motor sizes, decoilers, stackers, punching stations, and other features selected.
For a tailored quote based on your specific needs, please contact us.
If you have specific profile drawings, material types, or special features required, please send all relevant details to [email protected]. Our team will review your needs and provide a customized quotation designed to suit your project.
Note: All machines are new and custom-built to meet customers' specific profile and machine requirements. This machine can be delivered anywhere in the United Arab Emirates, including Abu Dhabi, Dubai, and Sharjah, directly from our manufacturing partner.
