Corrugated Drip Edge Roll Forming Machine – Alabama, USA

The Corrugated Drip Edge Roll Forming Machine is engineered to deliver precision and efficiency for contractors and manufacturers in Alabama, USA. Designed to create high-quality drip edge profiles, this machine is perfect for businesses looking to streamline production and enhance product quality. With a robust construction, advanced features, and the capability to produce multiple profiles, this machine is the ideal choice for roofing and siding applications across Alabama’s diverse climate and construction demands.

Machine Description

The Corrugated Drip Edge Roll Forming Machine is built with high-strength steel to withstand heavy usage while maintaining precision in every profile produced. It is equipped with a user-friendly PLC control system, enabling operators to input precise measurements and switch between different profiles effortlessly. The machine's high-speed operation ensures a production rate of 80 feet per minute, making it suitable for both small-scale and large-scale production requirements.

The electric shear cutting system ensures clean and accurate cuts, reducing material waste. With a compact footprint of 18ft x 3ft x 5ft and a weight of 2500 lbs, this machine can fit comfortably in most production facilities without requiring excessive space.

Specifications

• Weight: 2500 lbs
• Machine Size: 18ft x 3ft x 5ft
• Power Requirement: 240V, Three Phase, 60 Hz
• Speed: 80 ft per minute
• Stations: 10 stands
• Cutting System: Electric shear
• Control System: PLC with touchscreen interface
• Material Thickness: 0.3mm – 0.8mm (customizable based on requirements)
• Material Compatibility: Steel, Aluminum, Galvanized Steel, and other metals
• Warranty: 1-year limited warranty on parts and service
• Pricing: Based on optional extras and customization requirements. Contact us for a tailored quote.

Available Drip Edge Profiles and Sizes

This machine supports a wide range of drip edge profiles to cater to various architectural requirements:

• C5, C6, F4
• 90 Degree
• D Style
• FHA
• Custom Profiles: Available upon request for unique project specifications.

Optional Extras

• Remote PLC System: For enhanced control and monitoring.
• Stackers: To streamline product handling post-production.
• Coil Car Tippers: For efficient coil management.
• Uncoilers and Recoilers: To facilitate smooth material feed.
• Leveling Systems: To ensure flat and uniform material feeding.

Setup and Installation

Our team offers complete setup and installation services within Alabama and nearby states. Installation includes machine calibration, testing, and operator training to ensure seamless integration into your production line.

Maintenance Requirements

• Weekly: Check and lubricate moving parts.
• Monthly: Inspect and tighten bolts and electrical connections.
• Quarterly: Conduct a full diagnostic test and update PLC software if required.

Our maintenance team is available for on-site support and service contracts to ensure maximum uptime and efficiency.

Frequently Asked Questions (FAQs)

Q1: What is the lead time for the Corrugated Drip Edge Roll Forming Machine?

A: Typically, the lead time ranges from 6 to 8 weeks, depending on customization requirements.

Q2: Can this machine produce custom drip edge profiles?

A: Yes, we offer customization options for profiles based on your project specifications. Please contact us with your profile drawings for a tailored solution.

Q3: What type of materials can this machine handle?

A: The machine is designed to process a variety of metals including steel, aluminum, and galvanized steel with a thickness range of 0.3mm to 0.8mm.

Q4: Is on-site training available in Alabama?

A: Yes, we provide comprehensive on-site training to ensure your operators are fully equipped to manage the machine efficiently.

Q5: How is the pricing determined?

A: Pricing depends on optional extras and customization requirements. Contact us for a detailed quote based on your specific needs.

Q6: What is the warranty coverage?

A: The machine comes with a 1-year limited warranty covering parts and service.

Contact Us for a Quote

For more information and a tailored quote, please contact our sales team. We’ll help you choose the right configuration and optional extras to meet your production needs.
