Metal Decking Panel Roll Forming Machine - Colorado, USA

Product Description

The Metal Decking Panel Roll Forming Machine is an industrial-grade roll forming system designed to manufacture high-quality metal decking panels efficiently. Engineered to meet the demands of the construction and infrastructure industries, this machine is ideal for producing composite metal decks, B decks, N decks, and steel form decks. The machine is custom-built to accommodate various profile sizes and specifications, ensuring precision and durability for structural applications.

Designed for businesses in Colorado and the USA, this roll forming machine operates with a fixed base or cassette-style setup, offering flexibility in production. It features high-speed forming capabilities, heavy-duty construction, and an advanced pre-flying shear cutting system, allowing seamless deck panel production with minimal downtime.

Industry Applications

The Metal Decking Panel Roll Forming Machine is widely used in the following industries:

• Construction & Infrastructure – Production of composite floor decks, roof decks, and steel form decks used in commercial and industrial buildings.
• Steel Fabrication & Manufacturing – High-speed panel forming for large-scale steel component manufacturing.
• Bridge & Highway Construction – Forming structural decking for highways, bridges, and pedestrian walkways.
• Industrial Warehouses & High-Rise Buildings – Creation of robust metal decks to reinforce flooring and roofing structures.

Machine Specifications

• Forming Speed: 60 ft/min and above
• Material Thickness: 18g - 22g
• Machine Weight: 20 tons
• Machine Footprint: 85 ft
• Main Power Supply: 480V - 3PH - 60Hz
• Motor Power: 32 HP
• Drive System: Gearbox & Chain Drive
• Stations: 28 forming stations
• Cutting System: Pre-Flying Shear
• Safety Features: Optional safety covers, E-stops for emergency shutdown
• Uncoiler: 15,000 lb Hydraulic Uncoiler with Car
• Available Configurations: Fixed Base and Cassette Machines
• Automation: Auto stackers available
• Custom Profiles: Machines can be configured for custom profile requirements

Customization & Ordering

All machines are built new and custom-designed to meet the specific profile and operational requirements of our customers. Once manufactured, the machine will be shipped directly to your location in Colorado, USA.

Pricing is customized based on optional features and specific production needs. For a detailed quote, contact us and provide your desired profile specifications, production volume, and any additional requirements.

For profile drawings or additional information, email us at [email protected].

Warranty & Support

• One-Year Warranty from the date of dispatch.
• Maintenance and Repair Support to ensure longevity and high performance.
• Setup and Adjustment Services available upon request.

Frequently Asked Questions (FAQs)

Q: Can this machine produce different metal deck profiles?
A: Yes, the machine is capable of producing 1.5-inch B deck, 3-inch N deck, composite metal deck, and steel form deck profiles. Custom profiles can also be designed based on customer needs.

Q: What power supply does the machine require?
A: The machine operates on 480V, 3-phase, 60Hz power supply, which is standard for industrial applications in the USA.

Q: How fast can this machine produce metal decking panels?
A: The forming speed exceeds 60 feet per minute, ensuring high production efficiency.

Q: What safety features are included?
A: The machine includes E-stops for emergency shutdown and has optional safety covers available upon request.

Q: Can I add an auto-stacker to the machine?
A: Yes, auto stackers are available to streamline production and improve efficiency.

Q: How long does it take to receive the machine after placing an order?
A: Lead times vary based on customization. Please contact us for the latest production and shipping estimates.

Q: Do you offer installation and training?
A: Yes, installation and machine setup services are available upon request. We also provide training to ensure optimal machine operation.

Q: Where is this machine manufactured?
A: Our machines are custom-built by our manufacturing partners and shipped directly to your location in Colorado, USA.
