Type A Decking narrow rib roll forming machine Florida

The Type A Decking Narrow Rib Roll Forming Machine is a state-of-the-art manufacturing system designed to produce narrow rib decking profiles that meet structural and aesthetic requirements for flooring and roofing applications. This machine ensures precise, high-speed production, suitable for both commercial and industrial construction projects in Florida, where narrow rib decking is commonly used due to its excellent load distribution and fire resistance.

The machine is designed to handle a variety of materials, including galvanized steel, aluminum, and other coated metals, providing flexibility for manufacturers catering to Florida’s diverse construction industry. With advanced automation, PLC control systems, and customizable configurations, the machine guarantees superior output quality while minimizing operational costs.

Specifications

1. Roller Materials
   • High-quality GCr15 steel
   • Heat-treated and chrome-plated for extended durability
2. Punching and Notching
   • Hydraulic punching and notching systems
   • Precision for custom hole placements
3. Frame Structure
   • Heavy-duty steel frame for vibration reduction
   • Powder-coated finish for corrosion resistance
4. Motors and Drive System
   • Main motor: 15-20 HP (varies based on customization)
   • Servo motors for high-speed operations
   • Chain or gearbox drive systems
5. Hydraulic Cutting System
   • Material: Cr12Mov steel blades
   • Heat-treated for longevity and sharpness
   • Programmable cutting length
6. PLC Control System
   • Brand: Siemens or Mitsubishi
   • Touchscreen interface for user-friendly operation
   • Multi-language support
7. Machine Speed
   • Up to 30 meters per minute (varies based on profile complexity)
8. Safety Features
   • Enclosed guards for rollers and cutting zones
   • Emergency stop buttons
   • Overload protection systems
9. Profile Material
   • Material: Galvanized steel, aluminum, pre-painted steel
   • Thickness: 0.6 mm to 1.2 mm
   • Width: Customizable to meet narrow rib specifications
10. Optional Extras
    • Automatic stacker for efficient product handling
    • Remote PLC operation
    • Leveling systems for material alignment
    • Coil car tipper for loading heavy coils

Question and Answer Section

Q1: What industries commonly use the Type A decking narrow rib profile in Florida?
A: In Florida, narrow rib decking is widely used in the construction industry, particularly for commercial buildings, industrial facilities, and parking garages. Its fire resistance and load distribution capabilities make it a preferred choice.

Q2: How does the machine handle material variations?
A: The machine is designed to process a variety of materials, including galvanized and pre-painted steel, and aluminum, accommodating different thicknesses between 0.6 mm and 1.2 mm. Adjustable rollers ensure consistent quality regardless of the material.

Q3: Can the machine be customized for Florida’s specific construction codes?
A: Yes, the machine can be configured to produce profiles that meet Florida’s stringent building codes and hurricane resistance standards.

Q4: What is the average production capacity of this machine?
A: The production capacity depends on the profile complexity and material thickness. On average, the machine can produce up to 30 meters of decking per minute.

Q5: What are the maintenance requirements?
A: Regular maintenance involves lubrication of rollers, inspection of the hydraulic system, sharpening of cutting blades, and checking the PLC for software updates or calibration.

Q6: Is technical support available in Florida?
A: Yes, manufacturers often provide technical support, remote assistance, and on-site installation services in Florida.
