Roll forming machines have become essential tools in modern manufacturing, construction, and infrastructure development—especially in emerging markets like Comoros. Though a smaller island nation in the Indian Ocean, Comoros is witnessing increased demand for affordable and sustainable building materials, especially in sectors like housing, commercial infrastructure, and transportation.
In this guide, we’ll explore the most popular types of roll forming machines used in Comoros, their technical specifications, the profiles they produce, which industries use them, and the key areas in the country where they are most in demand. We’ll also cover machine maintenance, pricing, setup, operation, and the leading manufacturers in the region. Finally, we’ll explain how Machine Matcher helps you find the right roll forming machine to suit your profile and project needs.
Specifications:
Roller Material: GCr15 steel with hard chrome coating
Frame: 350–450 H-beam welded structure
Cutting System: Hydraulic with Cr12 mold steel blade
PLC System: Delta or Siemens-based automation
Speed: 10–15 meters per minute
Power: 380V/50Hz or customized
Profiles Produced:
Trapezoidal roofing sheets, corrugated roofing sheets, and standing seam panels.
Used In:
Residential and commercial construction, particularly for low-cost housing and weather-resistant structures.
Specifications:
Changeable C and Z profile sizes (80–300mm web sizes)
Adjustable punching units for bolt holes
Servo motor-driven shearing
PLC Touch Screen with manual and auto modes
Speed: Up to 20 meters per minute
Profiles Produced:
C and Z purlins used in roof and wall framing.
Used In:
Commercial building frameworks, warehouse structures, and solar panel support systems.
Specifications:
Roller Stations: 20–25 stations
Frame: 400H beam welded structure
Tile pressing system with servo control
Thickness range: 0.3–0.6 mm
Output speed: 5–8 meters per minute
Profiles Produced:
Metal glazed roof tiles with traditional clay-tile appearance.
Used In:
Residential buildings, resorts, and cultural architecture that blends modern durability with traditional aesthetics.
Specifications:
Compact 8–12 roller stations
Hydraulic or pneumatic cutting
Profile widths: 100mm–300mm
Material Thickness: 0.3–0.7 mm
Manual or motorized decoilers available
Profiles Produced:
Roof ridge caps that finish and seal the peaks of roofs.
Used In:
Roofing systems across residential, public buildings, and small factories.
Despite being a relatively small market, the following sectors are showing steady growth and actively use roll forming machines:
Construction & Housing: For affordable metal roofing, cladding, purlins, and framing systems.
Agriculture: For building storage sheds, greenhouses, and animal enclosures.
Renewable Energy: In solar infrastructure for panel supports and mounting structures.
Transportation: For vehicle workshops and storage sheds.
Roll forming machines are primarily used in the following regions:
Moroni (Grande Comore): The capital city and hub for construction and infrastructure projects.
Mutsamudu (Anjouan): An industrial port city with growing demand for metal buildings and storage.
Fomboni (Mohéli): A smaller city with rising interest in prefab housing and agricultural storage solutions.
These cities are the focal points for development, attracting both private investment and government-funded construction programs.
Proper maintenance is key to machine longevity and optimal performance:
Daily Cleaning: Remove debris, dust, and leftover metal scraps.
Lubrication: Regularly oil bearings, chains, and roller shafts.
Roller Inspection: Check for wear and re-polish or replace if necessary.
Hydraulic System Checks: Monitor fluid levels and inspect hoses for leaks.
Electrical System Tests: Ensure PLCs and sensors are functioning correctly.
Alignment Checks: Regularly inspect and adjust roller alignment to avoid uneven profiles.
Preventive maintenance should be scheduled monthly, with more intensive inspections performed quarterly.
Low-Cost Machines (Used or Basic Models):
$15,000 – $30,000
Ideal for startup operations, low-volume production, or limited profile sizes.
Mid-Range Machines (Standard Automation):
$30,000 – $60,000
These include PLC systems, hydraulic cutters, and decent speed.
High-End Machines (Fully Automatic & High Speed):
$60,000 – $150,000+
For large-scale manufacturers looking for precision, high output, and multiple profile production.
Installation:
Foundation Preparation: Ensure the machine is placed on level concrete flooring.
Electrical Connection: Set up the correct voltage and wiring in line with the PLC requirements.
Hydraulic Station Setup: Fill hydraulic oil and test the pressure system.
Profile Calibration: Input desired profile dimensions into the control system.
Trial Run: Start with a test coil, adjust roller gaps, and monitor accuracy.
Operation Tips:
Always load coil material securely.
Start with manual mode until all parameters are verified.
Regularly check alignment and feed rates during production.
Use trained operators familiar with PLC interface and safety procedures.
As of now, Comoros does not have local manufacturers of roll forming machines. Most machines are imported from:
China: A leading exporter of affordable and custom-designed machines.
India: Known for supplying durable machines suited for tropical climates.
Turkey and Europe: Higher-end machines with advanced automation.
South Africa and Kenya: Regional suppliers offering used machines and support.
Buyers in Comoros typically work through agents or importers to purchase roll forming machines tailored to local power and profile requirements.
Q1: What power supply is required for these machines in Comoros?
Most machines run on 380V, 3-phase power, but customizations for 220V systems are possible. Always confirm voltage with your supplier.
Q2: Can I use locally sourced steel coil for production?
Yes, but ensure the coil width and thickness match machine specifications. Quality should be checked for flatness and zinc coating if using galvanized steel.
Q3: Are spare parts and after-sales service available in Comoros?
Spare parts are usually shipped from the manufacturer. Some regional service providers or import agents can assist with installation and basic repairs.
Q4: Can one machine make multiple profiles?
Yes, but it depends on the machine type. Some advanced machines support interchangeable cassettes or adjustable roller settings for multiple profiles.
Q5: Is it better to buy new or used machines?
New machines offer better warranty and support, while used machines are more affordable but may require reconditioning. It depends on your budget and production goals.
At Machine Matcher, we specialize in helping businesses in emerging markets like Comoros find the perfect roll forming machine. Whether you need roofing panels, purlins, or ridge caps, we match your profile needs with the best-fit machines from trusted global manufacturers.
Our process ensures:
Tailored machine quotes based on your profile drawing, coil specs, and local voltage
Access to both new and used machines to match any budget
Support with shipping, installation, and setup
Expert advice on machine maintenance and operation
We understand the unique challenges of operating in Comoros and work closely with buyers to ensure smooth procurement from start to finish.
