Metal Roof Sheet Roll Forming Machine in China
- Condition
- New
- Supplier
- Roll Forming Machines China
- Country
- China
- Category
- Listing ID
- 10319
Request a Quote
To express an interest in this machine please submit the form below.
- Model No.:YY –HSR-002
- Type:Metal Tile Forming Machine
- Voltage:38oV/3Phase/50Hz Or At Customer’s Request
- Control System:PLC
- Warranty:12 Months
- Forming Speed:25-30m/min
- Material:GI, PPGI, Aluminum Coils
- Thickness:0.35-0.8mm
- Delivery:50 Days
- Cutting Mode:Mechanical Cutting
Automatic High Speed Metal Roof Sheet Roll Froming Machine
Our Automatic High Speed Metal Roof Sheet Roll Froming Machine .Speed 25-30m/min ,the speed double than normal machine.
The machine with Mechanical cutting to suits the high speed require.cut only 1 second.
All the electric part are Mitsubishi brand ,include: PLC , Touch screen,Frequency converter.
Roll forming machines metal roofing , Metal galvanized coils as raw material, PLC control, Chain transmission, has fast speed,feature of high stabilization
Working Flow: Decoiler – Feeding Guide – Main Roll Forming Machine – PLC Contol System – Hydraulic Cutting – Output Table
| Raw materials | Galvanized coils, Pre-painted coils, Aluminum coils |
| Material thickness range | 0.35-0.8mm |
| Forming speed | 25-30m/min |
| Rollers | 21 rows(according to drawings) |
| Material of rollers | 45# steel with chromed |
| Shaft material and diameter | 75mm, material is 45#steel |
| Material of body | 400H steel |
| Wall panel | 20mm Q195 steel(all with electrostatic spraying) |
| Controlling system | PLC |
| Main power | 7.5KW |
| Material of cutting blade | Cr12 mould steel with quenched treatment |
| Voltage | 380V/3Phase/50Hz |
| Total weight | about 4 tons |
