Aluminium Façade Roll Forming Machine – United Arab Emirates (uae)

Aluminium Façade Roll Forming Machine – Location: United Arab Emirates (UAE) For delivery across Abu Dhabi, Dubai, Sharjah & beyond

Product Overview

The Aluminium Façade Roll Forming Machine from Machine Matcher is a high-precision, heavy-duty roll forming solution engineered specifically for architectural and cladding applications. Designed for continuous production of aluminium panel profiles used in façades, curtain walls, architectural screens, and wall cladding systems, this machine delivers outstanding profile accuracy, long-term durability, and high-speed production.

Manufactured to meet the region’s construction and façade demands, this roll forming machine is ideal for aluminium profile manufacturers, façade contractors, and panel processing facilities throughout the UAE. Every machine is custom-built to match your exact profile specifications and operational requirements.

Industries Served

Machine Matcher’s Aluminium Façade Roll Forming Machine is engineered for industries where precision, aesthetic appeal, and structural integrity are paramount:

• Construction & Architecture: Aluminium cladding systems, ventilated façades, decorative metal panels
• Commercial Building Projects: Curtain wall backing panels, aluminium louvres, building wraps
• Industrial Applications: Insulated sandwich panel skins, protective aluminium covers
• Interior Fit-Outs: Aluminium wall systems, decorative trims

Industry Use Examples

• In Architecture: Custom aluminium profiles are used to clad high-rise buildings in Dubai and Abu Dhabi.
• In Industrial Projects: Panels formed using this machine serve as corrosion-resistant sheeting in coastal construction.
• In Interiors: Aluminium screen walls and dividers with intricate profiles are easily formed with high repeatability.

Machine Type & Capabilities

This is a fully automatic aluminium profile roll forming machine, equipped with a programmable control system, precision ground rollers, and optional punching or notching capabilities. Designed for high-volume and high-speed production, it supports multiple profile sizes with tight tolerances and can be equipped with embossing or coating lines if needed.

Technical Specifications

• Machine Type: Aluminium Façade Roll Forming Machine
• Production Speed: 10–25 meters/min (depending on profile complexity)
• Material Thickness Range: 0.5–1.5 mm
• Material Width Range: Up to 600 mm
• Material Types: Aluminium (1050, 1060, 1100, 3003, 5052), Pre-painted Aluminium
• Material Yield Strength: Up to 250 MPa (36 ksi)
• Roller Material: High-grade GCr15 steel
• Roller Surface Treatment: Hard chrome coated for anti-wear and smooth finish
• Number of Forming Stations: 14–22 stations (depending on profile shape)
• Roller Shaft Diameter: 70 mm
• Shaft Material: 45# Steel, precision-machined
• Main Drive Type: Chain or Gear-driven system
• Power (for UAE): 380V / 50Hz / 3 Phase
• Motor Power: 11–15 kW
• Cutting Method: Hydraulic cut-off system
• Blade Material: Cr12Mov, heat-treated for long life
• Control Type: PLC control with HMI touchscreen interface
• Operating Mode: Fully Automatic / Manual override
• De-coiling System: Hydraulic decoiler, 5-ton capacity
• Punching/Notching System (if included): Servo-driven punching system available
• Machine Frame: Welded steel base, stress-relieved
• Thickness of Frame Steel: 20 mm
• Profile Shape: Custom aluminium façade or cladding profiles
• Profile Width and Depth: Based on your drawings (typically 100–300 mm width, 20–50 mm depth)
• Length Tolerance: ±1.0 mm per 6 meters

Safety & Operation

• Protective Covers/Guards over all moving parts
• Emergency Stop Button located at key operator positions
• Overload Protection System integrated into electrical cabinet

Customization Options

• Profile width, depth, and shape
• Integrated punching or notching
• Logo embossing system
• Colour marking system
• Dual-profile tooling
• Servo feeding and stacking system
• Coating or lamination add-ons

Unique Selling Points (USPs)

✅ Custom-built for aluminium profiles — Engineered for lightweight but strong material handling

✅ Highly accurate profile forming — Ensures sharp angles, clean finishes, and consistent panel sizing

✅ Durability built in — All rollers are hardened and treated for long service life

✅ Energy-efficient design — Optimized drive motors and PLC control reduce power consumption

✅ Modular and scalable — Can be extended or retooled for new profiles in future

✅ Fast lead times and expert installation — Delivered across UAE, with full commissioning support

Installation & Support

• Remote video guidance provided
• On-site installation and training available on request
• Covered by one-year warranty from dispatch
• Long-term spare parts and repair support from Machine Matcher

Questions & Answers

Q: Can the machine be customized for our aluminium façade profile?

A: Yes. All machines from Machine Matcher are built to your exact profile drawings and size needs.

Q: What is the lead time for manufacturing and shipping to UAE?

A: Production typically takes 30–60 days. Shipping time varies by port and customs process.

Q: Is remote installation support available?

A: Yes. We provide video support remotely, and on-site installation is available in UAE upon request.

Q: What type of aluminium material is typically used?

A: Common grades include 1050, 1100, and 3003 with thickness between 0.5–1.5 mm and yield strengths up to 36 ksi (250 MPa).

Q: What affects the final price of the machine?

A: Final pricing depends on profile complexity, included features (punching, dual-profile tooling), and level of automation.

Pricing

• Starting Price Range: From USD 45,000 (standard configuration)
• Pricing Variables: Custom tooling, motor power upgrades, integrated systems, automation level

Delivery & Location

All aluminium façade roll forming machines supplied by Machine Matcher are custom-built and can be delivered anywhere in the UAE, including major cities like Dubai, Abu Dhabi, Sharjah, and across the GCC.

Each order is tailored to your required profile drawings and operational needs. If you have profile samples or technical drawings ready, please send them to [email protected] for an accurate quotation and technical review.

Why Choose Machine Matcher

• Expertise in Custom Roll Forming Solutions
• All Machines Are New, Purpose-Built, and Delivered Ready for Production
• Full Support Team Based in the UK and USA
• Delivery Available Throughout UAE & Middle East
• Warranty, Maintenance, and Spare Parts Support Included

To get a tailored quote and consultation, contact Machine Matcher today with your profile drawings and machine requirements.
