JIH-CNC6500H 3-Axis CNC Machining Center (6,500mm) | JIH-I, Taichung, Taiwan

The JIH-CNC6500H is a 3-axis CNC machining center for long profiles and large components. It uses a travelling column with a fixed table, so the weight of the workpiece never loads the drive system, and machining accuracy stays consistent regardless of what is on the table. The table is 6,500mm long, which allows very long profiles to be machined in one setup.

The machine is built for heavy-duty work. The base is fabricated from heavy-gauge steel plate with reinforcement, and the oversized box-type column is made from high-quality cast iron. It uses 45mm P-class high-precision linear guideways on all three axes, an automatic lubrication system for all guideways and ball screws, and a 24-tool arm-type automatic tool changer.

Unlike the other models in JIH-I's 3-axis range, which are optimised for aluminium only, the H Type is the one that can also process iron. It handles aluminium, steel, cast iron, moulds, and other non-ferrous metals.

Why Choose a Travelling Column Machining Center?

On a conventional machine where the table moves, a heavy or very long workpiece loads the drive system and can affect accuracy. With a travelling column and fixed table, the workpiece stays still and the column moves, so consistent accuracy doesn't depend on part weight.

For long-profile work, this matters:

• Long parts in one setup. A 6,500mm table (with shorter X-axis options of 3,500, 4,500, and 5,500mm) suits long aluminium and steel profiles.
• Rigid construction. The heavy steel base, cast iron column, and large, firmly supported X-axis ball screw are designed to avoid deflection.
• Multiple materials. Because it handles steel and cast iron as well as aluminium, one machine can cover mixed workloads, from curtain wall and window profiles to rail and machine body components.

Machine Specifications

Strokes and table

• X axis stroke: 6,500mm (optional 3,500 / 4,500 / 5,500mm)
• Y axis stroke: 510mm (optional 650mm)
• Z axis stroke: 510mm (optional 700mm)
• Distance from spindle nose to table surface: min. 160mm, max. 670mm
• Table type: 5-groove T-slot table
• Table size: 450 × 6,500mm (optional 600 × 6,500mm with the 650mm Y stroke)
• Maximum table load: 1,000kg
• T-slots (number × width × pitch): 5 × 94 × 450mm

Spindle

• Spindle speed: 12,000 r.p.m.
• Spindle motor: 15HP (11kW)
• Spindle taper: BT40 (optional BT50, 8,000 r.p.m.)

Feed and accuracy

• Rapid feed: X axis 40m/min with gear rack (optional ball screw 24m/min); Y axis 24m/min (ball screw); Z axis 24m/min (ball screw)
• Servo motors: X 5kW, Y 3.5kW, Z 3.5kW
• Cutting feed rate: 1 to 5,000mm/min
• Repeatability: X ±0.02mm, Y ±0.01mm, Z ±0.01mm

Automatic tool changer

• Magazine capacity: 24 tools
• ATC type: arm-type
• Tool holder: BT40
• Pull stud: 45°
• Maximum tool length: 300mm
• Maximum tool diameter: 80mm
• Maximum tool weight: 7kg

Dimensions and requirements

• Required pneumatic pressure: 6kg/cm²
• Machine dimensions (L × W × H): 15,000 × 3,200 × 3,000mm
• Packing dimensions (L × W × H): 11,800 × 2,300 × 2,500mm (2 × 40-inch containers)
• Machine weight: 15,000 to 21,000kg

Condition Available: New

JIH-I reserves the right to modify specifications without notice.

Key Features

• Travelling column with fixed table, so workpiece weight doesn't affect accuracy
• Heavy-gauge steel base and oversized cast iron box-type column
• 45mm P-class high-precision linear guideways on all three axes (X axis 8 blocks, Y and Z axes 6 blocks; each Y guideway carries 3 sliding blocks)
• Large-diameter X-axis ball screw, firmly supported to avoid self-deflection
• Automatic lubricator for all guideways and ball screws
• 24-tool arm-type automatic tool changer
• Handles aluminium, steel, cast iron, moulds, and other non-ferrous metals

Applicable Materials

• Aluminium
• Steel
• Cast iron
• Moulds
• Other non-ferrous metals

Applications

• Aluminium doors and windows
• Curtain wall (glass wall) profiles
• Train rail components
• Steel knives
• Machine body and frame components

Who This Machine Is For

• Aluminium profile processors who also need to machine steel or cast iron
• Curtain wall, door, and window fabricators machining long profiles in one setup
• Rail, tooling, and machine builder workshops needing a long-bed machining center

Frequently Asked Questions

What materials can it machine?
Aluminium, steel, cast iron, moulds, and other non-ferrous metals. It is the only model in JIH-I's 3-axis range that can process iron.

How long a workpiece can it machine?
The X axis stroke is 6,500mm as standard, with shorter options of 3,500, 4,500, and 5,500mm.

How accurate is it?
Repeatability is ±0.02mm on the X axis and ±0.01mm on the Y and Z axes.

Why does the travelling column design matter?
The table is fixed, so workpiece weight doesn't load the transmission system, and machining accuracy stays consistent across long strokes.

How many tools does the changer hold?
24 tools, using an arm-type changer with BT40 tool holders (BT50 optional).

What space and shipping should I plan for?
The machine is 15,000mm long and weighs 15,000 to 21,000kg. It ships in two 40-inch containers, so plan for a strong floor, crane or forklift access, and a long clear bay.

Is financing or staged payment available?
Yes. A deposit secures your order and begins production, with the remaining balance due only once your machine has been built, inspected, and is ready to ship.

Should I buy new or used?
This model is available new, from a manufacturer that has built aluminium processing machinery since 1971.
