MDT-200 Automatic Beam Bar Drilling Machine for Aluminium Formwork | CGMA, Jinan, China

The MDT-200 is an automatic machine for high-speed drilling of the holes in aluminium formwork beam bars. The beam bar holder can be loaded with 20 or more beam bars at a time, and the machine then runs the whole cycle by itself: it automatically feeds the beam bars, drills the holes, and unloads the finished products.

The holes are made with a high-speed shaft motor that mills them quickly and leaves a smooth surface without burrs. Because loading is done in batches of 20 or more, an operator can load the magazine and attend to other tasks while the machine works through the bars.

The machine is compact, at 1,000 × 600 × 1,700mm and about 400kg, so it fits into a formwork production line without needing much floor space.

Why Choose an Automatic Beam Bar Drilling Machine?

Beam bars need accurately positioned holes, and drilling them one at a time by hand is repetitive and slow. Automating the feed, drill, and unload cycle removes most of the handling.

• Batch loading. The holder takes 20 or more beam bars per load.
• Hands-off cycle. Feeding, drilling, and unloading all happen automatically.
• Clean holes. The high-speed shaft motor gives fast drilling and a smooth, burr-free finish.
• Small footprint. Roughly 1m × 0.6m on the floor.

Machine Specifications

• Input voltage: 3-phase, 380V, 50Hz
• Input power: 5.0kW
• Working air pressure: 0.5 to 0.8MPa
• Air consumption: 120L/min
• Overall dimensions (L × W × H): 1,000 × 600 × 1,700mm
• Weight: approx. 400kg
• Beam bar holder capacity: 20 or more beam bars per load

Condition Available: New

Key Features

• Beam bar holder loads 20 or more bars at once
• Fully automatic feeding, drilling, and unloading
• High-speed shaft motor for fast hole milling
• Smooth surface without burrs
• Compact footprint of 1,000 × 600mm

Applications

• Drilling holes in aluminium formwork beam bars
• High-volume aluminium formwork component production

Who This Machine Is For

• Aluminium formwork manufacturers
• Formwork producers who want to automate a repetitive drilling step
• Workshops making beam bars in volume

Frequently Asked Questions

What does this machine do?
It automatically drills the holes in aluminium formwork beam bars. It feeds the bars, drills them, and unloads the finished pieces without operator input.

How many beam bars can it hold?
The holder can be loaded with 20 or more beam bars at one time.

How good is the hole quality?
The high-speed shaft motor mills the holes quickly and leaves a smooth surface without burrs.

What power and air does it need?
3-phase 380V, 50Hz power at 5.0kW, plus compressed air at 0.5 to 0.8MPa with 120L/min consumption.

How big and heavy is it?
It measures 1,000 × 600 × 1,700mm and weighs about 400kg.

Is financing or staged payment available?
Yes. A deposit secures your order and begins production, with the remaining balance due only once your machine has been built, inspected, and is ready to ship.

Should I buy new or used?
This model is available new, from a manufacturer with 23 years of experience in aluminium processing machinery.
