Pipe Convey System for Welded Pipe Production Lines (Finishing Section)

Huaye (Taiyuan Huaye Heavy Industry): Taiyuan, Shanxi, China

A complete, custom-laid-out finishing section for a welded pipe plant: conveyors, ejectors, delivery cars, rotators, weld repair stations, slag removal, and pipe droppers, all from one supplier.

The Pipe Convey System covers everything that happens to pipe after it leaves the mill: moving it along the line, turning it, inspecting it, repairing weld defects, cleaning it, and placing it on racks. In a pipe plant this is called the finishing section. Huaye supplies it as a single package for spiral and ERW pipe lines, including the conveyors, racks, ejectors, rotating rollers, delivery cars, and simple process equipment such as slag removing machines and weld seam grinders.

Huaye's engineers design the layout around the customer's factory building, so the plan makes the best use of the available space. To get a layout, the customer determines the main equipment needed, confirms the size of the site, and provides or confirms the workshop drawing. Huaye then designs the overall layout from those.

The equipment is built modularly, and Huaye tries to design each module to fit a standard shipping container, using frame or open-top containers, or bulk carriers, for oversize or overweight parts.

The Equipment in the System

• Driven conveyor: carries pipe lengthwise along the line
• Idle conveyor: a non-powered conveyor that carries pipe lengthwise
• Ejector: flips pipe from the conveyor or support rollers onto the rack
• Pipe delivery car: moves pipe sideways, and can replace the ejector for transfers between the rack and the conveyor
• Swinging pipe delivery cart: turns the direction of pipe travel by 90°
• Pipe rotator: turns the pipe, used for repair welding and manual inspection, normally together with a pipe ejector receiver
• Pipe lifting rotator: lifts and rotates the pipe, used for repair welding and manual inspection
• Weld repair station: repairs defective weld seams, combining a pipe rotator, an ejector receiver (or lift rotator), a welding arm, and a repair welding machine
• Slag removing machine: dumps slag out of the inside of the pipe
• Pipe dropper: lowers pipe gently onto the rack or to the next stage of production

Why Choose a Single-Supplier Finishing Section?

The finishing section links a lot of separate machines, and gaps between suppliers cause layout and handover problems. Buying it as one system, designed around your building, avoids that.

• Designed for your shed. The layout starts from your workshop drawing.
• One supplier. All finishing equipment comes from Huaye.
• Complete function. Conveying, flipping, turning, inspecting, repairing, and stacking.
• Modular shipping. Modules are sized to fit standard containers wherever possible.
• Full support. Design through installation, commissioning, training, and after-sales.

Machine Specifications

The page doesn't give numeric specifications. This is a made-to-order system, and each installation depends on your pipe sizes, weights, line speed, and workshop layout.

To get a quote you would normally provide:

• Pipe diameter, wall thickness, and length range
• Maximum pipe weight
• Production rate
• Workshop drawing and available space
• Which finishing machines you need (for example, beveling, hydrostatic testing, or expanding stations)

Condition Available: New, made to order

Key Features

• Complete pipe finishing section from one supplier
• Layout designed from your workshop drawing
• Includes conveyors, ejectors, delivery cars, rotators, weld repair stations, slag removal, and droppers
• Modular design sized for container shipping
• Works with spiral and ERW pipe lines

Applications

• Finishing and handling sections of spiral welded pipe mills
• Finishing sections of ERW pipe mills
• Weld repair, inspection, and pipe stacking areas

Who This Machine Is For

• Spiral and ERW pipe manufacturers building or expanding a plant
• Producers who want one supplier for the whole finishing section
• Plants moving from manual handling to a conveyed layout

Frequently Asked Questions

What does the system include?
Conveyors (driven and idle), ejectors, pipe delivery cars, swinging delivery carts, pipe rotators and lifting rotators, weld repair stations, slag removing machines, and pipe droppers.

How is the layout decided?
You confirm the main equipment and the site size, and provide or confirm the workshop drawing. Huaye's engineers design the layout from them.

What is a weld repair station?
A station for repairing defective weld seams on pipe. It combines a pipe rotator, an ejector receiver or lifting rotator, a welding arm, and a repair welding machine.

What does the slag removing machine do?
It tips slag out of the inside of the pipe.

How is it shipped?
The equipment is modular, designed to fit standard containers where possible, with frame containers, open-top containers, or bulk carriers for oversized parts.

Is financing or staged payment available?
Yes. A deposit secures your order and begins production, with the remaining balance due only once your machine has been built, inspected, and is ready to ship.

Should I buy new or used?
This system is available new, built to your layout.
