Jinbolida 10-Tonne Coil Loading Car – Safe, Accurate Coil Loading onto the Uncoiler

The Jinbolida Coil Loading Car automates the first step of any coil-fed production line: getting a heavy coil onto the uncoiler. It carries steel or aluminium coils of up to 10 tonnes on a V-shaped cradle, and a servo-driven lifting mechanism raises the coil with millimetre-level accuracy so its centre lines up with the uncoiler mandrel. A wireless remote control lets one operator load, centre and prepare the coil from a safe distance, removing the need for cranes and manual guidance at the mandrel. It's suitable for roll forming, cut-to-length, slitting and stamping lines.

How It Works

• The coil is placed on the V-shaped cradle
• The car travels to the uncoiler
• Servo-driven lifting raises the coil to the mandrel centre with millimetre-level accuracy
• The coil is pushed onto the mandrel ready for uncoiling
• The whole sequence is operated from a wireless remote control

Key Features

• Rated load up to 10 tonnes
• V-shaped cradle that holds coils securely and centres them
• Servo-driven lifting for millimetre-level positioning
• Accurate alignment with the uncoiler mandrel, reducing adjustments
• Wireless remote control for one-person operation from a safe distance
• Heavy-duty steel main frame with reinforced key parts
• Designed for long-term, high-frequency use with low maintenance

Technical Specifications

• Rated load: Up to 10 t
• Coil support: V-shaped cradle
• Lifting drive: Servo motor
• Positioning accuracy: Millimetre-level
• Control: Wireless remote control
• Coil materials: Steel and aluminium

Applications

• Roll forming lines for C/Z purlins, profiles and colour-coated steel sheet
• Cut-to-length and slitting lines
• Stamping lines for automotive panels and structural parts
• Appliance, hardware and packaging strip production
• Any coil-fed line where coils are loaded onto an uncoiler

Commercial Details

• Brand: Jinbolida
• Manufacturer: Shandong Jinbolida Precision Machinery Co., Ltd.
• Place of origin: Heze, Shandong, China

Frequently Asked Questions

• What does a coil loading car do? It carries a coil to the uncoiler and lifts it into line with the mandrel so it can be loaded without a crane.
• What coil weight can it handle? Up to 10 tonnes.
• How accurate is the lifting? Servo-driven lifting gives millimetre-level positioning.
• How many operators are needed? One, using the wireless remote control.
• What should I send for a quotation? Maximum coil weight, coil inner and outer diameters, coil width, uncoiler mandrel height, and travel distance.
