Cliplock / Klip-Lok Roll Forming Machine | MNM, Binh Duong, Vietnam

MNM's Cliplock Roll Forming Machine produces concealed-fix roof sheeting in the Klip-Lok style. The sheets clip over brackets fixed to the purlins, so no screws pass through the roof sheet, which keeps the roof watertight and allows long runs to expand and contract.

The ribbed clip profile is demanding to form and needs 25 to 33 stations. The line weighs 12 to 14 tonnes.

Technical Specifications

• Total power: 11–15 kW
• Weight: 12–14 t
• Rolling speed: 18–20 m/min
• Forming stations: 25–33
• Shaft diameter: Ø70 mm

Applications

• Concealed-fix roofs on commercial and industrial buildings
• Low-pitch roofs with long sheet runs
• Architectural roofing

Commercial Details

• Brand: MNM
• Manufacturer: MNM Industrial Mechanical Limited Company
• Place of origin: Thuan An City, Binh Duong, Vietnam

Frequently Asked Questions

• What is a cliplock roof? A concealed-fix roof where sheets clip onto brackets, so there are no exposed screws.
• How many stations does it have? 25–33, depending on profile.
• What should I send for a quotation? Your cliplock profile drawing, material and thickness, sheet lengths and output target.
