Double Layer Shutter Door Roll Forming Machine in Wuxi, China

Foam injection machine

1. Motor power: total 5.5 KW; 380V; 50/60HZ

2. Mixing head with one spare is included

3. Mixing pump quantity: 8g/Second

4. Density: 70 ~ 80 Kg/M³

5. Mixing type: mechanical & automatic

6. Washing: Automatic

7. Tank volume: 50 KG / tank. Both Poly and ISO

8. Brand of Foam machine: GREAT WALL.

PLC Control Cabinet

1. Touch screen brand: DELTA

2. PLC brand: DELTA

3. Inverter brand: DELTA

4. Main components for low pressure electricity: Schneider Germany

Output table

1. Length: 6 meters

2. Drive type: Rollers

CUTTING PLATFORM

1. Cutting type: Pneumatic Fly Saw cutter with servo control system

2. Motor brand: China top motor 4KW; 380V; 50/60HZ
