Floor Deck / Bondek Roll Forming Machine | MNM, Binh Duong, Vietnam

MNM's Floor Deck Roll Forming Machine produces steel floor decking in the Bondek style: a ribbed deck that acts as permanent formwork for a concrete slab and, once the concrete has cured, as part of its reinforcement.

Deck profiles are deep and need a lot of forming force, so this is one of MNM's heaviest lines, with up to 33 forming stations on shafts up to 115 mm and a weight of 18 to 22 tonnes. Each machine is configured to the customer's deck profile.

Technical Specifications

• Total power: 30–45 kW
• Weight: 18–22 t
• Rolling speed: 16–18 m/min
• Forming stations: 30–33
• Shaft diameter: Ø80–115 mm

Applications

• Composite floor slabs in steel-framed buildings
• Multi-storey commercial and residential buildings
• Mezzanines and car parks

Commercial Details

• Brand: MNM
• Manufacturer: MNM Industrial Mechanical Limited Company
• Place of origin: Thuan An City, Binh Duong, Vietnam

Frequently Asked Questions

• What is Bondek-style decking? A ribbed steel deck that supports wet concrete as formwork and then works with the slab as reinforcement.
• Why is the machine so heavy? Deep deck profiles need many stations and large shafts to form accurately.
• What should I send for a quotation? Your deck profile drawing, material grade and thickness, sheet lengths and output target.
