Jinbolida Steel Plate Punching Machine – Heavy-Duty Hydraulic Punching for Thick Steel Plate

The Jinbolida Steel Plate Punching Machine is a heavy-duty hydraulic press for punching holes in thick steel plate. A rigid four-column or double-frame structure absorbs the high punching forces without deflecting, and a deep throat lets the machine reach into large plates. Unlike plasma or oxy-fuel cutting, punching leaves no heat-affected zone, giving cleaner hole edges and better dimensional accuracy, which often removes the need for reaming or machining afterwards. It suits heavy fabrication shops working on structural steel, mining equipment, bridges, ships and industrial machinery.

Key Features

• High-pressure hydraulic system for heavy punching force
• Rigid four-column or double-frame construction that resists deflection
• Deep throat for punching large plates
• Large, heavy-duty worktable
• Massive, heat-treated tooling for long life
• Quick-change tooling to reduce downtime between hole sizes
• Clean, accurate holes in a single stroke

Configurable Options (to be confirmed with Jinbolida)

• Powered plate positioning system for moving heavy plates

Punching vs Thermal Cutting

• No heat-affected zone: Punching doesn't heat the steel, so the material around the hole isn't weakened
• Better hole quality: Cleaner edges and more accurate diameters than plasma or oxy-fuel cutting
• Less finishing: Often no need for reaming or secondary machining
• Faster: Each hole is made in a single stroke

Applications

• Structural steel nodes, base plates and connection plates
• Bridge construction components
• Mining equipment, wear plates and crusher components
• Shipbuilding plate
• Bases and frames for industrial machinery
• Heavy plate fabrication in general

Commercial Details

• Brand: Jinbolida
• Manufacturer: Shandong Jinbolida Precision Machinery Co., Ltd.
• Place of origin: Heze, Shandong, China

Frequently Asked Questions

• Why punch instead of plasma or oxy-fuel cutting? Punching leaves no heat-affected zone and gives cleaner, more accurate holes, often without secondary machining.
• What frame design does it use? A rigid four-column or double-frame construction. Ask Jinbolida which suits your application.
• Can tooling be changed quickly? Yes. Quick-change tooling minimises downtime when switching hole diameters.
• What should I send for a quotation? Plate material and thickness, plate size, hole diameters, required punching force, throughput, and your local voltage and frequency.
