Photovoltaic Bracket Production Line | Jinbolida, Shandong, China

Jinbolida Photovoltaic Bracket Production Line – C and Z Section PV Brackets from Coil to Finished Part

The Jinbolida Photovoltaic Bracket Production Line turns steel coil into finished, punched PV mounting brackets in one continuous, synchronised process. Coil is decoiled and levelled, roll formed into C-channels or Z-sections, punched with bolt holes and connection points, and cut to exact length, with automatic stacking available. Operators enter bracket length, hole pattern and quantity on the HMI, and the PLC runs the job, so switching between bracket designs is quick. With quick-change tooling, one line can produce a range of bracket profiles and sizes, serving both heavy-duty utility-scale projects and lighter rooftop systems.

Line Sequence

• Decoiling and levelling: Steel coil is unwound and flattened
• Roll forming: Forms C-channel or Z-section profiles
• Punching: High-speed punching of bolt holes and connection points
• Cut to length: Cuts each bracket to the programmed length
• Stacking or packing (optional): Finished brackets are stacked or packed automatically

Key Features

• Continuous, synchronised process from coil to finished bracket
• Produces C-channels and Z-sections for PV mounting
• High-speed punching of bolt holes and connection points
• PLC control with HMI panel for entering length, hole pattern and quantity
• Quick-change tooling for multiple bracket profiles and sizes
• Consistent dimensions across thousands of parts for trouble-free installation
• Reduced manual handling and labour per part

Key Benefits

• Consistency: Every bracket is virtually identical, avoiding fit problems on site
• Efficiency: Shorter cycle times and less labour per part lower unit costs
• Flexibility: Switch between bracket profiles and sizes with minimal downtime

Applications

• Utility-scale ground-mount solar farms needing heavy-duty supports
• Commercial rooftop arrays needing lightweight brackets
• C and Z purlins and brackets for PV mounting structures

Commercial Details

• Brand: Jinbolida
• Manufacturer: Shandong Jinbolida Precision Machinery Co., Ltd.
• Place of origin: Heze, Shandong, China
• Configuration: Built to customer bracket designs

Frequently Asked Questions

• What profiles can the line produce? C-channels and Z-sections, with other profiles possible using different tooling.
• How are jobs set up? Operators enter bracket length, hole pattern and quantity on the HMI, and the PLC controls the line.
• Can one line make different brackets? Yes. Quick-change tooling and programmable controls allow multiple profiles and sizes.
• Does it include stacking? Automatic stacking or packing can be added.
• What should I send for a quotation? Bracket drawings with hole patterns and lengths, material grade and thickness, strip width, required output, and your local voltage and frequency.
