Jinbolida Forming Discharge Unit – Automatic Take-Off and Stacking at the End of a Forming Line

The Jinbolida Forming Discharge Unit automates the discharge end of a roll forming line. As each formed part leaves the forming machine, a conveyor carries it away, a recognition system locates it, and a robot arm (or suction or custom end effector) picks it up and places it on a pallet, rack or the next machine. Conveyor speed is matched to the forming rhythm by servo or variable-frequency control, so parts flow off the line continuously without bumps or scratches. For solar bracket and building profile lines, it can count parts into fixed quantities or turn and nest them for compact stacks, removing the manual handling that often limits line speed.

How It Works

• The formed part leaves the forming machine onto the discharge conveyor
• Conveyor speed is synchronised with the forming rhythm
• A recognition system locates the part
• A robot arm or end effector picks the part
• The part is placed on a pallet, rack or the next machine, in fixed quantities or turned and nested stacks

Key Features

• Automatic take-off of formed parts from the forming machine
• Conveyor with servo or variable-frequency speed control, matched to the forming rhythm
• Recognition system for part positioning
• Robot arm, suction cups or custom end effectors
• Fixed-quantity counting and turned (nested) stacking for profiles
• Careful handling to avoid bumps and scratches on finished parts
• Modular design: conveyor length and robot model configured to the part and workshop layout
• Can be connected to forming machines of different makes

Applications

• C and U purlins and solar bracket profiles from roll forming lines
• Building profiles
• Pipes and bars from laser cutters, tube benders and saws, sorted by size
• Stamped parts from punch presses
• Automotive, appliance and furniture parts at the end of automated lines

Which Jinbolida Line-End System Fits?

• Forming Discharge Unit (this unit): Conveyor and robot arm take-off and stacking at the end of a forming line
• Automated Pallet Storage: Gantry robot stacking into high-density storage racks
• Finished Part Unloader with Flip Function: Collection, flipping and stacking of small stamped parts

Commercial Details

• Brand: Jinbolida
• Manufacturer: Shandong Jinbolida Precision Machinery Co., Ltd.
• Place of origin: Heze, Shandong, China
• Configuration: Built to the customer's parts, line and layout

Frequently Asked Questions

• What does the discharge unit do? It takes formed parts off the end of the line and stacks or transfers them automatically.
• Does it keep up with the forming machine? Yes. Conveyor speed is controlled by servo or VFD to match the forming rhythm.
• Can it stack purlins nested together? Yes. It can turn parts for nested stacking and count them into fixed quantities.
• Will it work with our existing forming machine? It's designed to connect with different makes. Ask Jinbolida about your specific machine.
• What should I send for a quotation? Profile types, sizes, lengths and weights, line speed, stacking pattern and bundle quantities, and your available floor space.
