Jinbolida Sheet Metal Hole Punching Machine – Fast, Precise Hole Punching for Thin and Medium Sheet

The Jinbolida Sheet Metal Hole Punching Machine is built for high-speed, high-precision punching of thin to medium-gauge metal sheet. A rigid frame and fast mechanical or servo-mechanical drive deliver high stroke rates without losing accuracy, while programmable X and Y backgauges position each hole precisely. It punches standard round holes as well as squares, oblongs and louvres, producing clean, burr-free parts that need no deburring. Quick-change tooling keeps changeovers short, so the machine suits both long runs of identical parts and short runs of custom work in HVAC, electrical enclosure and metal furniture production.

Key Features

• Designed for thin to medium-gauge sheet metal
• Mechanical or hybrid servo-mechanical drive for high stroke rates
• Rigid frame that maintains accuracy at high punching speeds
• Worktable with precision-ground guides
• Programmable X and Y backgauges for accurate hole positioning
• Round, square, oblong and louvre tooling, plus custom shapes
• Quick-change tooling to minimise downtime between jobs
• Clean, burr-free holes, ready to use without deburring
• Tool sensors and automatic sheet clamps for safe operation

Configurable Options (to be confirmed with Jinbolida)

• CNC control that runs hole patterns directly from CAD files
• Auto-indexing tooling

Applications

• HVAC ductwork: louvres and tap holes
• Electrical control panels and enclosures
• Ventilation grilles
• Decorative perforated screens
• Metal furniture assembly holes
• General sheet metal fabrication

Which Jinbolida Punching Machine Fits?

• Sheet Metal Hole Punching Machine (this machine): Flat thin to medium sheet
• Steel Plate Punching Machine: Thick, heavy steel plate
• Channel Steel Punching Machine: C-purlins and U-channels
• Angle Iron Punching Machine: L-shaped angle sections
• Tube Punching Machine: Round, square and rectangular tube

Commercial Details

• Brand: Jinbolida
• Manufacturer: Shandong Jinbolida Precision Machinery Co., Ltd.
• Place of origin: Heze, Shandong, China

Frequently Asked Questions

• What sheet thickness can it punch? Thin to medium-gauge sheet. Ask Jinbolida for the exact thickness range.
• What hole shapes can it punch? Round holes as standard, plus squares, oblongs, louvres and custom shapes with the right tooling.
• Is it suited to short runs? Yes. Programmable positioning and quick-change tooling make short custom runs cost-effective.
• Do parts need deburring? No. The machine produces clean, burr-free holes.
• What should I send for a quotation? Sheet material and thickness, sheet size, hole shapes, sizes and patterns, required output, and your local voltage and frequency.
