Single Layer Roll Forming Machine with Curving Head | MNM, Binh Duong, Vietnam

MNM's Single Layer Roll Forming Machine with Curving Head forms one roofing profile and can curve the sheets in line, producing straight and curved sheets from the same machine.

It has 18 to 28 stations and weighs 8 to 10 tonnes.

Technical Specifications

• Total power: 5.5–7.5 kW
• Weight: 8–10 t
• Rolling speed: 18–20 m/min
• Forming stations: 18–28
• Shaft diameter: Ø70 mm

Applications

• Arched roofs and canopies
• Straight and curved roof sheets

Commercial Details

• Brand: MNM
• Manufacturer: MNM Industrial Mechanical Limited Company
• Place of origin: Thuan An City, Binh Duong, Vietnam

Frequently Asked Questions

• Can it make straight sheets too? Yes. Curving is applied when needed.
• How fast is it? 18–20 m/min.
• What should I send for a quotation? Your profile drawing, curve radii, material and thickness.
