Solar Bracket Punching Machine Line | Jinbolida, Shandong, China

Jinbolida Solar Bracket Punching Machine Line – High-Speed CNC Hole Punching for PV Mounting Brackets

The Jinbolida Solar Bracket Punching Machine Line is a dedicated CNC punching system for making the bolt holes, slots and notches in solar mounting brackets. Built for high-volume photovoltaic bracket production, it pairs a heavy-duty punching press with a servo-driven feed, punching complete hole patterns quickly and accurately so it keeps pace with an upstream roll forming line. Switching to a new bracket design is a matter of loading a new CNC program and, where needed, changing tools on a quick-change system, making the line well suited to manufacturers handling many bracket designs and custom orders.

How It Works

• Pre-cut blanks or lengths of roll-formed profile are fed into the line
• A servo feed positions the material precisely for each hole
• The CNC system controls feed length and press strokes to punch the full hole pattern for bolts, screws and locating pins
• Finished, ready-to-assemble brackets leave the line, while scrap is removed automatically

Key Features

• Dedicated punching line, cycling faster than multi-purpose machines
• CNC programming for fast changeover between bracket hole patterns
• Servo-driven material feeding for accurate hole spacing
• Heavy-duty punching press (mechanical or hydraulic, depending on configuration)
• Quick-change tooling to minimise downtime between runs
• Clean, burr-free holes with accurate spacing for proper bolt fit
• Job-specific tooling for longer tool life and lower cost per part
• Scrap removal system to keep the work area clear
• Designed to match the output of high-speed roll forming lines

Configurable Options (to be confirmed with Jinbolida)

• Multi-head punching units
• Robotic part handling to punch multiple faces in one cycle
• Integration with Jinbolida roll forming lines for a complete forming and punching solution

Applications

• Solar mounting bracket production
• C and Z purlins, rails and connectors for PV racking
• Ground-mount and rooftop solar structure components
• Other high-volume punched steel profiles

Commercial Details

• Brand: Jinbolida
• Manufacturer: Shandong Jinbolida Precision Machinery Co., Ltd.
• Place of origin: Heze, Shandong, China
• Support: Operator training included to help customers get the most from the line (per Jinbolida)

Frequently Asked Questions

• What does the line do? It punches bolt holes, slots and notches in solar mounting brackets at high speed.
• Can it handle different bracket designs? Yes. Changing designs means loading a new CNC program and, if needed, changing tools on the quick-change system.
• Does it work with a roll forming line? It's designed to match the speed of an upstream roll forming line, and Jinbolida also supplies roll forming machines for solar brackets.
• Is training provided? Jinbolida offers training programmes so operators can use the line effectively.
• What should I send for a quotation? Bracket drawings with hole patterns, material grade and thickness, profile or blank dimensions, required output, and your local voltage and frequency.
