Jinbolida Finished Part Unloader with Flip Function – Automatic Collecting, Flipping and Stacking for Stamping Lines

The Jinbolida Finished Part Unloader with Flip Function is an end-of-line unit for punching and stamping presses. It solves a common press shop problem: parts dropping from the die in random positions, then being collected and stacked by hand in inconsistent orientations. The unit gathers parts from the press into collection lanes, locates each one with vision or sensors, and transfers it with a high-precision servo mechanism or robot arm. An intelligent flipping module turns parts 180° or to a set angle so every part faces the same way, before placing them neatly into totes, onto pallets or packing tables, or onto the next assembly line.

How It Works

• Parts falling from the press die are collected automatically
• A vibratory feeder or multi-lane guide rails bring parts to a central station
• Vision or sensors locate each part's position and orientation
• A servo transfer mechanism, suction transfer or robot arm picks each part
• The flipping module turns the part 180° or to a set angle as required
• Parts are placed in a consistent orientation and pattern into totes, onto pallets or onto a conveyor

Key Features

• End-of-line unit for punching and stamping presses
• Automatic collection of parts from the press
• Vibratory feeder or multi-lane collection rails
• High-precision servo transfer or robot arm handling
• Intelligent flipping module (180° or set angle)
• Vision or sensor-based part positioning
• Programmable stacking patterns and quantities
• Modular design, adjustable for part width, stacking pattern and flip angle
• Gentle handling to avoid scratching parts
• Removes manual picking pauses to raise overall equipment effectiveness (OEE)

Applications

• Automotive stamped parts: door hinges, seat adjusters, seat belt components
• Appliance and hardware parts: air conditioner metalwork, casings, lock parts
• Electrical and electronic stamped parts: connector terminals, heat sinks
• New energy and motor parts: battery connectors, motor stator and rotor laminations, relay housings
• General metal stamping with any press output needing orderly collection

Commercial Details

• Brand: Jinbolida
• Manufacturer: Shandong Jinbolida Precision Machinery Co., Ltd.
• Place of origin: Heze, Shandong, China
• Configuration: Built to suit the customer's parts and press line

Frequently Asked Questions

• What does the unit do? It collects parts from a punch or stamping press, turns them to a consistent orientation and stacks them neatly.
• Why is flipping needed? Many parts have a front and back. Flipping ensures they all face the same way for assembly or packing.
• How are parts handled? By a servo transfer mechanism, suction transfer or robot arm, depending on the parts.
• Can it handle different parts? Yes. Part width, stacking pattern and flip angle can be adjusted.
• What should I send for a quotation? Part drawings or samples, weights, press speed (strokes per minute), required orientation and stacking pattern, and where the parts need to go (totes, pallets or conveyor).
