Steel Roof Decking Roll Forming Machine Alabama

Steel roof decking machines are essential for the construction industry, offering precision and efficiency in producing high-quality decking profiles for various applications. These machines are designed to cater to Alabama's growing demand for durable and versatile steel roofing and decking solutions.

Machine Description

The steel roof decking machine is engineered for reliability, speed, and versatility. It is capable of producing multiple profiles, including 1.5-inch B deck, 3-inch N deck, composite metal deck, and steel form deck profiles, all customizable to meet specific project requirements. Whether you need fixed-base machines or cassette-based systems, these machines offer adaptability for diverse construction needs.

The machine comes with advanced features like auto stackers, enhancing operational efficiency, and supports both standard and custom profile production, making it an ideal choice for construction companies and fabricators in Alabama.

Specifications

Forming Machine

• Forming Speed: 60+ ft/min
• Material Thickness: 18g - 22g
• Machine Weight: 20 tons
• Machine Footprint: 85 ft
• Main Power: 480V, 3-phase, 60Hz
• Motor: 32 HP
• Drive System: Gearbox & Chain drive
• Stations: 28
• Cutting Type: Pre-Flying Shear
• Safety Features: Optional safety covers and E-Stops

Uncoiler with Hydraulic Car

• Decoiling Speed: 60 ft/min
• Max Loading Capacity: 15,000 lbs
• Coil Width: 48 inches
• Machine Weight: 3.5 tons
• Machine Footprint: 14 ft x 6 ft x 6 ft
• Car Size: 35" x 28"
• Controls: Jog controls with proximity sensors and air brakes

Optional Features

• Auto Stackers: Enhance stacking efficiency and reduce manual labor.
• Safety Covers: Optional for enhanced workplace safety.
• Custom Profiles: Machines can be tailored for unique profile requirements.

Applications

Steel roof decking machines are widely used in:

• Commercial and industrial building projects
• Parking garages
• Bridges
• High-rise construction
• Warehouses

These machines meet the specific needs of Alabama's construction industry, ensuring compliance with local building standards and durability under varying weather conditions.

FAQs

1. What profiles can this machine produce?

The machine can produce 1.5-inch B deck, 3-inch N deck, composite metal deck, and steel form deck profiles. Custom profiles can also be made based on your specifications.

2. What is the forming speed of this machine?

The forming speed is over 60 ft per minute, making it highly efficient for large-scale production.

3. Can the machine handle different material thicknesses?

Yes, the machine is designed to handle material thicknesses ranging from 18g to 22g.

4. Does the machine come with an uncoiler?

Yes, the machine includes a 15,000 lb uncoiler with a hydraulic car for efficient coil handling.

5. Are safety features included?

The machine comes with optional safety covers and E-stops to ensure a safe operating environment.

6. Can the machine be customized?

Absolutely! We offer customization for specific profile requirements, ensuring the machine meets your project needs.

7. What power requirements does this machine have?

The machine operates on 480V, 3-phase, 60Hz power.

8. Is training provided for setup and operation?

Yes, we provide comprehensive training to ensure your team can efficiently set up and operate the machine.

This steel roof decking machine is a valuable investment for businesses in Alabama seeking reliable, high-speed, and versatile production capabilities. With customizable options and advanced features, it ensures quality and efficiency for any project.
