Used Daewoo Puma 12L CNC Lathe | A.K. Machine Traders, Navi Mumbai, India

This used Daewoo Puma 12L CNC lathe is available from A.K. Machine Traders in Navi Mumbai, India. It is a turning centre that machines round parts by rotating the workpiece against tools held in a turret.

It turns up to 18.89 in diameter and 40.2 in length, and takes bar up to 3.54 in. The spindle runs at 12–2500 RPM with a 30 HP motor, and the 12-station turret indexes in 1 second.

Key Features

• 12-station turret with a 1-second index time
• MT-5 tailstock with a 4.33 in quill
• A2-8 spindle nose with a 4.13 in bore

Technical Specifications

• Model: Daewoo Puma 12L
• Max turning diameter: 18.89 in
• Max turning length: 40.2 in
• Max bar capacity: 3.54 in
• Swing over bed: 22.4 in
• Distance between centres: 42.0 in
• X axis travel: 10.2 in
• Z axis travel: 41.3 in
• X axis rapid traverse: 480 IPM
• Z axis rapid traverse: 630 IPM
• Spindle nose: A2-8
• Spindle bore: 4.13 in
• Spindle speed: 12–2500 RPM
• Spindle motor: 30 HP
• Turret capacity: 12 stations
• Turret index time: 1 second
• Tailstock taper: MT-5
• Tailstock quill diameter: 4.33 in
• Tailstock quill travel: 4.0 in

Applications

• Turned shafts and spindles
• Round components machined between centres
• Bar-fed turned parts
• General engineering and production turning

Commercial Details

• Make: Daewoo
• Model: Puma 12L
• Condition: Used
• Location: Navi Mumbai, Maharashtra, India
• Seller: A.K. Machine Traders

Frequently Asked Questions

• What is the maximum bar capacity? The Puma 12L takes bar up to 3.54 in.
• How fast does the spindle run? The spindle runs at 12–2500 RPM, driven by a 30 HP motor.
• How many tool stations does it have? It has a 12-station turret with a 1-second index time.
• What should I ask when enquiring? Ask for photos or video of the machine running under power, whether an inspection can be arranged, which chuck, tooling and accessories are included, the control type and electrical details, and the loading and shipping arrangements.
