Used Enshu F130 Drill Tap Center | A.K. Machine Traders, Navi Mumbai, India

This used Enshu F130 drill tap center is available from A.K. Machine Traders in Navi Mumbai, India. It is a compact vertical machining centre for drilling and tapping, with a BT-30 spindle that runs from 40 to 15,000 rpm.

The table measures 600 x 400 mm and carries up to 200 kg. Travels are 500 x 400 x 300 mm (X x Y x Z). An arm-type tool changer holds 12 + 1 tools, with 20 + 1 available as an option.

Key Features

• Arm-type automatic tool changer
• Tool magazine of 12 + 1 tools, optionally 20 + 1
• Tool-to-tool change time of 0.18 sec
• Wide spindle speed range of 40–15,000 rpm

Technical Specifications

• Model: Enshu F130
• Table size: 600 x 400 mm
• Travel (X x Y x Z): 500 x 400 x 300 mm
• Table load: 200 kg
• Spindle speed: 40–15,000 rpm
• Spindle taper: BT-30
• Tool change time (tool to tool / chip to chip): 0.18 / 1.8 sec
• Tool capacity: 12 + 1 (optional 20 + 1)
• Tool change method: Change arm
• Machine weight: 2,300 kg
• Machine size (W x L x H): 1,400 x 2,695 x 2,165 mm

Applications

• Drilling and tapping of small metal parts
• Machining of small components in batch production
• Light milling of small precision parts

Commercial Details

• Make: Enshu
• Model: F130
• Condition: Used
• Location: Navi Mumbai, Maharashtra, India
• Seller: A.K. Machine Traders

Frequently Asked Questions

• What is the table size and load capacity? The table is 600 x 400 mm and takes up to 200 kg.
• What spindle does it have? It has a BT-30 taper spindle running at 40–15,000 rpm.
• How many tools does the magazine hold? It holds 12 + 1 tools, with a 20 + 1 option, loaded by a change arm.
• What should I ask when enquiring? Ask for photos or video of the machine running under power, whether an inspection is possible, which tooling and accessories are included, the control and electrical details, and the loading and shipping arrangements.
