Used Lorenz LS 420 Gear Shaper | A.K. Machine Traders, Navi Mumbai, India

This used Lorenz LS 420 gear shaper is available from A.K. Machine Traders in Navi Mumbai, India. A gear shaper cuts gear teeth using a reciprocating cutter.

It takes parts up to 420 mm in external diameter and handles gears up to module 7 with 12–150 teeth. Maximum gear width is 120 mm and the stroke is 125 mm.

Technical Specifications

• Model: Lorenz LS 420
• Maximum external part diameter: 420 mm
• Maximum internal part diameter: 370 mm
• Maximum module: 7
• Number of teeth: 12–150
• Spindle diameter: 100 mm
• Table diameter: 400 mm
• Table bore: 125 mm
• Stroke: 125 mm
• Gear width: 120 mm
• Raiseblock: 150 mm

Applications

• External spur and helical gears for general engineering
• Internal gears up to 370 mm
• Gears for gearboxes and power transmission
• Small-batch and workshop gear production

Commercial Details

• Make: Lorenz
• Model: LS 420
• Condition: Used
• Location: Navi Mumbai, Maharashtra, India
• Seller: A.K. Machine Traders

Frequently Asked Questions

• What is the largest part this machine can cut? It handles external part diameters up to 420 mm and internal part diameters up to 370 mm, with a gear width of 120 mm.
• What gear sizes can it cut? It cuts up to module 7 with 12–150 teeth.
• What is the table size? The table is 400 mm in diameter with a 125 mm bore.
• What should I ask when enquiring? Ask for photos or video of the machine running under power, whether an inspection is possible, which cutter holders, tooling and change gears are included, the condition of the control and electrics, and the loading and shipping arrangements.
