Used OOYA RE2-1450A Radial Drill | A.K. Machine Traders, Navi Mumbai, India

This used OOYA RE2-1450A radial drill is available from A.K. Machine Traders in Navi Mumbai, India. A radial drill drills holes in workpieces using a spindle carried on a swinging arm.

It has a 1,450 mm arm and drills steel to 40 / 50 mm diameter. The spindle takes MK 5 tooling and runs at 32–1,655 rpm, with feeds of 0.08–1.0 mm per revolution. Total power requirement is 3.7 kW.

Technical Specifications

• Model: RE2-1450A
• Drilling capacity in steel (diameter): 40 / 50 mm
• Arm length: 1,450 mm
• Vertical stroke: 600
• Tool taper: MK 5
• Spindle speed range: 32–1,655 rpm
• Feeds: 0.08–1.0 mm/rev
• Total power requirement: 3.7 kW
• Dimensions (approx.): 2.4 x 0.9 x 2.35 m
• Weight (approx.): 3.5 t

Applications

• Drilling holes in large or heavy steel workpieces
• General workshop and fabrication drilling
• Machining holes in castings and welded structures

Commercial Details

• Make: OOYA
• Model: RE2-1450A
• Condition: Used
• Location: Navi Mumbai, Maharashtra, India
• Seller: A.K. Machine Traders

Frequently Asked Questions

• What size holes can it drill? It drills steel to 40 / 50 mm diameter.
• What spindle speeds and feeds does it offer? Spindle speed is 32–1,655 rpm and feed is 0.08–1.0 mm per revolution.
• How big and heavy is the machine? It measures approximately 2.4 x 0.9 x 2.35 m and weighs approximately 3.5 t.
• What should I ask when enquiring? Ask for photos or video of the machine under power, whether an inspection is possible, which tooling and accessories are included, the condition of the electrics and voltage, and loading and shipping arrangements.
