Used Pfauter PA 210 Gear Hobbing Machine | A.K. Machine Traders, Navi Mumbai, India

This used Pfauter PA 210 gear hobbing machine is available from A.K. Machine Traders in Navi Mumbai, India. A gear hobbing machine cuts teeth into gear blanks with a rotating hob.

It handles wheels up to 220 mm in diameter and up to module 6, from 4 to 60 teeth. The hob slide has 250 mm of axial travel, and the machine has a conventional control unit.

Technical Specifications

• Model: Pfauter PA 210
• Max. wheel diameter: 220 mm
• Max. module: 6
• Number of teeth: 4–60
• Max. axial travel of hob slide: 250 mm
• Max. hob diameter: 163 mm
• Max. hob length: 230 mm
• Shifting: 170 mm
• Centre distance, workpiece to tool: 40–200 mm
• Dividing plate diameter: 324 mm
• Table diameter: 240 mm
• Table hole: 80 mm
• Milling arbor diameter: 32 mm
• Voltage: 220 / 380 V, 50 Hz
• Control unit: Conventional
• Weight: approx. 9,200 kg

Applications

• Cutting spur and helical gears in small to medium sizes
• Producing gear wheels with 4–60 teeth
• Gear manufacture for general engineering and machinery

Commercial Details

• Make: Pfauter
• Model: PA 210
• Condition: Used
• Location: Navi Mumbai, Maharashtra, India
• Seller: A.K. Machine Traders

Frequently Asked Questions

• What size of gear can it cut? It cuts wheels up to 220 mm in diameter, up to module 6, with 4–60 teeth.
• What hob size does it take? It takes hobs up to 163 mm in diameter and 230 mm long on a 32 mm milling arbor.
• What is the machine weight and power supply? It weighs approximately 9,200 kg and runs on 220 / 380 V, 50 Hz.
• What should I ask when enquiring? Ask for photos or video of the machine under power, whether an inspection is possible, which hobs, arbors and change gears are included, the condition of the electrics and control, and loading and shipping arrangements.
