Used Trident TR 603 Drill-Tap Center | A.K. Machine Traders, Navi Mumbai, India

This used Trident TR 603 drill-tap centre is available from A.K. Machine Traders in Navi Mumbai, India. It is a compact vertical machining centre for drilling, tapping and light milling, built in 2011.

The TR 603 has a BT30 spindle with direct drive, 600 × 400 × 350 mm of travel and a 700 × 420 mm table. Its arm-type tool magazine holds 20+1 tools with a tool-to-tool time of 1.5 seconds.

Key Features

• Direct-coupled spindle drive
• Arm-type automatic tool changer
• Fully enclosed, heat-isolated electrical cabinet
• Spindle air blow device and work light
• Tool coolant system and screw-type chip removal
• Automatic lubrication system
• Dual-colour LED alarm light and TFT LCD monitor

Technical Specifications

• Model: Trident TR 603 (TR-60 series)
• X travel: 600 mm
• Y travel: 400 mm
• Z travel: 350 mm
• Table to spindle nose: 150–500 mm
• Table size: 700 × 420 mm
• Maximum table load: 250 kg
• T-slots: 14 × 100 × 4 mm
• Spindle taper: BT30 (7/24 No. 30)
• Spindle speed: 60–10,000 min-1 standard
• Maximum tapping speed: 4,000 rpm
• Spindle transmission: Direct drive
• Rapid traverse: X, Y 48 m/min; Z 60 m/min
• Cutting feed rate: 10,000 mm/min
• Tool magazine: 20+1 tools, arm type
• Maximum tool length: 200 mm
• Maximum tool diameter: 63 mm
• Tool change time: 1.5 sec tool to tool; 1.9 sec chip to chip
• Axis motors: X, Y 1.5 kW (Mitsubishi) or 1.2 kW (Fanuc); Z 3.0 kW
• Spindle motor: 3.7/2.2 kW
• Dimensions (W × D × H): 165 × 252 × 280 cm
• Net weight: 3,250 kg

Applications

• Drilling and tapping small parts
• Light milling of components
• Automotive and electronic parts machining
• Batch production of small machined components

Commercial Details

• Make: Trident
• Model: TR 603
• Year: 2011
• Condition: Used
• Location: Navi Mumbai, Maharashtra, India
• Seller: A.K. Machine Traders

Frequently Asked Questions

• What spindle does the TR 603 have? It has a BT30 direct-drive spindle running at 60–10,000 min-1 as standard, with rigid tapping up to 4,000 min-1.
• How big is the work area? Travels are 600 mm in X, 400 mm in Y and 350 mm in Z, over a 700 × 420 mm table that carries up to 250 kg.
• Which controls are available on this series? The TR-60 series is offered with Mitsubishi M70 and M80 controls and Fanuc 0i-MF controls.
• What should I ask when enquiring? Ask for photos or video of the machine running under power, which control is fitted, and whether tooling, tool kit and any optional accessories are included. Also confirm the electrical supply, inspection options, and loading and shipping arrangements.
