Vision-Guided Automatic Loading Feeder ±0.5 mm | Jinbolida, Shandong, China

Jinbolida High-Precision Automated Feeder – Vision-Guided Loading of Parts and Blanks onto Production Machines

The Jinbolida High-Precision Automated Feeder automates the step between the raw material buffer and the main processing machine. Batches of blanks, sheets or parts are loaded into its storage bins. The unit then locates each one with a machine vision system, picks it with a servo-driven manipulator or gantry, and places it on the downstream machine's worktable or feed unit with an accuracy within ±0.5 mm. Multi-layer storage with material-level management lets it hold several batches and release them in time with production, supporting continuous, mixed-product runs. Its modular design means it can be adapted to different part sizes and connected to punch presses, laser machines and CNC equipment.

How It Works

• Batches of blanks or parts are loaded into multi-layer storage bins or buffer belts
• The vision system identifies and locates each part
• A servo-driven manipulator or gantry picks the part
• The part is placed on the downstream machine's worktable or feed unit within ±0.5 mm
• The feed sequence adjusts to the production pace

Key Features

• Machine vision positioning for automatic part recognition
• High-precision servo-driven manipulator or gantry
• Placement accuracy within ±0.5 mm
• Multi-layer storage bins or buffer belts with material-level management
• Stores several batches and adjusts the feed sequence to the production pace
• Suitable for small-batch, multi-product (mixed) production
• Core components from international brands (to be confirmed)
• Sturdy structure designed for continuous running
• Modular design, customisable to part size, shape and workshop layout
• Connects to punch presses, laser machines and CNC equipment of different makes

Technical Specifications

• Placement accuracy: Within ±0.5 mm
• Positioning: Machine vision
• Drive: Servo
• Handling: Manipulator or gantry
• Storage: Multi-layer bins or buffer belts

Applications

• Loading sheets, strips and blanks onto punch presses (automotive parts, motor cores, connectors)
• Loading sheets, tubes and parts onto laser cutting and welding machines
• Loading raw material into CNC machine tools
• Feeding parts into vision inspection or measuring stations
• Loading parts into assembly workstations

Loading and Unloading Automation from Jinbolida

• High-Precision Automated Feeder (this unit): Loads parts onto the production machine
• Finished Part Unloader with Flip Function: Collects, orients and stacks parts coming off the press
• Automated Pallet Storage: Gantry robot stacking and rack storage for long profiles at the line end

Commercial Details

• Brand: Jinbolida
• Manufacturer: Shandong Jinbolida Precision Machinery Co., Ltd.
• Place of origin: Heze, Shandong, China
• Configuration: Custom-built to the customer's parts and machines

Frequently Asked Questions

• What does the feeder do? It automatically picks blanks or parts from storage and places them on the next machine.
• How accurate is it? Placement accuracy is within ±0.5 mm.
• How does it locate parts? With a machine vision positioning system.
• What machines can it feed? Punch presses, laser machines, CNC machine tools and other processing equipment, depending on configuration.
• What should I send for a quotation? Part or blank dimensions and weight, how parts are supplied (stacked, loose, in trays), the target machine and its cycle time, and your available floor space.
